8.7.3 UL Compliance

Fuse classification for UL Compliance
UL COMPLIANCE
To comply with NEC 2017, it is mandatory to use fuses or circuit breakers. Danfoss recommends using a selection of the fuses
listed in the following tables. These fuses are suitable for use on a circuit capable of delivering 100000 A
480 V, 500 V, or 600 V depending on the drive voltage rating. With the proper fusing, the drive short circuit current rating (SCCR)
is 10000 A .
rms
For semiconcutor fuse types, the drive controller and the overcurrent protection device must be integrated within the same overall
assembly.
Table 46: UL Fuse Classification Chart
UL class Fuse overload characteristics
RK1 Ultra fast-acting
T Fast-acting
J Fast-acting
CC Fast acting
