VLT® AutomationDrive FC 301/FC 302
Operating Guide
Table 47: Recommended Maximum UL Fuse Class, Voltage Range 3x200–240 V, Enclosure Sizes A, B, and C
Class fuses
Power [kW (hp)] RK1/J/T [A]
0.25–0.37 (0.34–0.5) 5
0.55–1.1 (0.75–1.5) 10
1.5 (2.0) 15
2.2 (3.0) 20
3.0 (4.0) 25
3.7 (5.0) 30
5.5 (7.5) 50
7.5 (10.0) 60
11.0 (15.0) 80
15–18.5 (20.0–25.0) 125
22.0 (30.0) 150
30.0 (40.0) 200
37.0 (50.0) 250
Table 48: Recommended Maximum UL Fuse Class, Voltage Range 380–500 V, Enclosure Sizes A, B, and C
Class fuses
Power [kW (hp)] RK1/J/T [A]
0.37–1.1 (0.5–1.5) 6
1.5–2.2 (2.0–3.0) 10
3.0 (4.0) 15
4.0 (5.0) 20
5.5 (7.5) 25
7.5 (10.0) 30
11.0 (15.0) 40
15.0 (20.0) 50
18.5 (25.0) 60
22.0 (30.0) 80
30.0 (40.0) 100
37.0 (50.0) 125
45.0 (60.0) 150
55.0 (75.0) 200
75.0 (100.0) 250
80 | Danfoss A/S © 2021.01
Semiconductor fuses
CC [A] SIBA Littelfuse
5 5017906-005 –
10 5017906-010 –
15 5017906-016 –
20 5017906-020 –
25 5017906-025 –
30 5012406-032 –
– 5014006-050 –
– 5014006-063 –
– 5014006-080 –
– 2028220-125 –
– 2028220-150 L25S-150
– 2028220-200 L25S-200
– 2028220-250 L25S-250
Semiconductor fuses
CC [A] SIBA Littelfuse
6 5017906-006 –
10 5017906-010 –
15 5017906-016 –
20 5017906-020 –
25 5017906-025 –
30 5012406-032 –
– 5014006-040 –
– 5014006-050 –
– 5014006-063 –
– 2028220-100 –
– 2028220-125 –
– 2028220-125 –
– 2028220-160 –
– 2028220-200 L50-S-225
– 2028220-250 L50-S-250
Ferraz-Shawmut (Mersen)
–
–
–
–
–
–
–
–
–
–
A25X-150
A25X-200
A25X-250
Ferraz-Shawmut (Mersen)
–
–
–
–
–
–
–
–
–
–
–
–
–
A50-P-225
A50-P-250
AQ267037727118en-000101 / 130R0300
Specifications
Bussmann (Eaton)
FWX-5
FWX-10
FWX-15
FWX-20
FWX-25
FWX-30
FWX-50
FWX-60
FWX-80
FWX-125
FWX-150
FWX-200
FWX-250
Bussmann (Eaton)
FWH-6
FWH-10
FWH-15
FWH-20
FWH-25
FWH-30
FWH-40
FWH-50
FWH-60
FWH-80
FWH-100
FWH-125
FWH-150
FWH-200
FWH-250
