VLT® AutomationDrive FC 301/FC 302
Operating Guide
Enclo- 200–240 V [kW (hp)]
sure
size
B3 5.5–7.5 (7.5–10.0)
B4 11–15 (15-20)
C1 15–22 (20– 30)
C2 30–37 (40– 50)
C3 18.5–22 (25–30)
C4 37–45 (50– 60)
Danfoss A/S © 2021.01
380–500 V [kW (hp)] 525–690 V [kW
(hp)]
11–15 (15-20) –
18.5–30 (25–40) 11–30 (15-40)
30–45 (40– 60) –
55–75 (75– 100) 30–75 (40– 100)
30–37 (40– 50) 37–45 (50– 60)
55–75 (75– 100) 11–22 (15-30)
Purpose
Relay.
Ground.
Mains, brake resistor, load
sharing, motor cables.
Relay.
Ground.
Mains, brake resistor, load
sharing, motor cables.
Relay.
Ground.
Mains, brake resistor, load
sharing cables.
Motor cables.
Relay.
Ground.
Mains, motor cables.
Load sharing, brake cables.
Relay.
Ground.
Mains, brake resistor, load
sharing, motor cables.
Relay.
Ground.
Mains, motor cables.
Load sharing, brake cables.
Relay.
Ground.
AQ267037727118en-000101 / 130R0300 | 83
Specifications
Tightening torque
[Nm] ([in-lb])
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
1.8 (15.9)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
4.5 (39.8)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
10 (89)
10 (89)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
14 (124) (up to 95
2
mm (3 AWG))
2
24 (212) (over 95 mm
(3 AWG))
14 (124)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
10 (89)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
14 (124) (up to 95
2
mm (3 AWG))
2
24 (212) (over 95 mm
(3 AWG))
14 (124)
0.5–0.6 (4.4–5.3)
2–3 (17.7–26.6)
