VLT® AutomationDrive FC 301/FC 302
Operating Guide
Type designation
Continuous kVA (575 V) [kVA]
Maximum input current
Continuous at 550 V [A]
Intermittent at 550 V [A]
Continuous at 575 V [A]
Intermittent at 575 V [A]
Additional specifications
Estimated power loss at rated maximum load [W]
(2)
Efficiency
(3)
High overload=150% or 160% torque for a duration of 60 s. Normal overload=110% torque for a duration of 60 s.
1
Applies for dimensioning of drive cooling. If the switching frequency is higher than the default setting, the power losses may increase. LCP and
2
typical control card power consumptions are included. For power loss data according to EN 50598-2, refer to Danfoss
Efficiency measured at nominal current. For energy efficiency class, see
3
mart website.
8.1.4 Mains Supply 525–690 V (FC 302 only)
Table 38: A3 Enclosure, Mains Supply 525–690 V IP20/Protected Chassis, P1K1–P7K5
Type designation
High/normal overload
(1)
Typical shaft output [kW/(hp)]
Enclosure protection rating IP20
Output current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–690 V) [A]
Intermittent (551–690 V) [A]
Continuous kVA 525 V
Continuous kVA 690 V
Maximum input current
Continuous (525–550 V) [A]
Intermittent (525–550 V) [A]
Continuous (551–690 V) [A]
Intermittent (551–690 V) [A]
Additional specifications
Danfoss A/S © 2021.01
P37K P45K
51.8 61.7 61.7
49 59 59
74 65 89
47 56 56
70 62 85
740 900 900
0.98 0.98
8.4 Ambient Conditions. For part load losses, see Danfoss
P1K1 P1K5 P2K2
HO/NO HO/NO HO/NO
1.1 (1.5) 1.5 (2.0) 2.2 (3.0)
A3 A3 A3
2.1 2.7 3.9
3.4 4.3 6.2
1.6 2.2 3.2
2.6 3.5 5.1
1.9 2.5 3.5
1.9 2.6 3.8
1.9 2.4 3.5
3.0 3.9 5.6
1.4 2.0 2.9
2.3 3.2 4.6
P55K
82.7 82.7 99.6
78.9 78.9 95.3
87 118 105
75 75 91
83 113 100
1100 1100 1500
0.98
MyDrive® ecoSmart
P3K0 P4K0
HO/NO HO/NO
3.0 (4.0) 4.0 (5.0)
A3 A3
4.9 6.1
7.8 9.8
4.5 5.5
7.2 8.8
4.5 5.5
5.4 6.6
4.4 5.5
7.0 8.8
4.0 4.9
6.5 7.9
AQ267037727118en-000101 / 130R0300 | 67
Specifications
P75K
99.6 130.5
95.3 124.3
143 137
91 119
137 131
1500 1800
0.98
website.
MyDrive® ecoS-
P5K5 P7K5
HO/NO HO/NO
5.5 (7.5) 7.5 (10)
A3 A3
9.0 11
14.4 17.6
7.5 10
12 16
8.2 10
9.0 12
8.1 9.9
12.9 15.8
6.7 9.0
10.8 14.4
