Mode Item/Display
Setting of the L LO-COV
execution
conditions of
the process
M TonerCA-END
control
N AVERAGE-PAGE
O LIMIT PAGE
P PIX_RATIO_BK
Q PIX_RATIO_CL
R INTERVAL TIME
S HUM HOUR
T HUM_DIF
U BK_RATIO
V M_RATIO
W COLOR BORDER
X BK ONLY
Y HT_DIF
Setting of the Z RG_ON_
execution SYNC
condition of the
registration
adjustment
AA RG_TEMP_TIMER
AB RG_PERM_TIMER
AC RG_HOUR_TIMER
AD RG_BW_SYNC
Setting of the execution judgment of the
process control in continuous printing of
low print ratio images
Setting of the process control interval
reduction when the toner cartridge
remaining quantity is 25% or less (If this is
set to Enable, item M RATIO is changed.)
Setting of the number of pages of item HI-
COV set value 2
Setting of the number of connected jobs of
the process control and of the limit number
of the process control
A number of reservation jobs are
connected. When the number of jobs
exceeds the specified number of pages
(the set value of this setting), the process
control is performed. / The process control
is performed by AND conditions of item
REV condition and the specified number of
pages (the set value of this setting).
Magnification ratio setting (%) of the BK toner count specified value
The set value of 100 corresponds to K print of A4 at the print ratio of 5%.
Magnification ratio setting (%) of the color (CMY) toner count specified
value
The set value of 100 corresponds to K print of A4 at the print ratio of 5%.
Setting of the leaving time when turning ON the power (including the
sleep recovery time) (h: hour)
Interval setting of the temperature and humidity monitoring time of
"HUM" (unit: 10 minutes)
The specified value of the area difference in humidity between the level
at execution of the previous control and the current humidity (Applied to
item HUM)
Magnification ratio setting (%) of the specified value of the BK OPC
drum traveling distance of "REV2_BK"
Magnification ratio setting (%) of the M OPC drum traveling distance of
"REV2_CL"
Judgment criteria whether the BK high
density process control is individually
performed or not (Setting of the ratio of the
M OPC drum rotation distance for the K
OPC drum rotation distance (%))
Setting of the frequency of execution of the
4-color high density process control when
only monochrome output is continued (The
result of this setting is applied only when
the M OPC drum rotation distance is
smaller than the set value of COLOR
BORDER.)
HT process control execution judgment developing bias variation value
CL Setting of execution of the registration adjustment when executing the
process control when turning ON the power
ALL
CL/BK
Time interval from registration adjustment after turning ON the power to
the next execution.
Setting of inhibit time of execution of the registration adjustment
Setting of the interval time of execution of the registration adjustment
Setting of Enable/Disable of the
registration adjustment after a
monochrome job
MX-3114N SIMULATION 6 – 62
Content
Enable
Inhibit
Enable
Inhibit
1: 10 pages - 5: 50 pages
1 step corresponds to 10
pages.
1: 10 pages - 10: 100
pages
1 step corresponds to 10
pages.
0: The BK process control
is executed regardless of
the M OPC drum traveling
distance.
1 - 999: 1 - 999(%)
Frequency of once for 5
times
Frequency of once for 1 - 5
times
The 4-color high density
process control is always
performed.
Enable
Inhibit
Default
Setting range
value
0 - 1 0 0
1
0 - 1 0 1
1
1 - 5 1 3
5
1 -10 1 10
10
1 - 999 10
1 - 999 10
1 - 255 3
1 - 24 2
1 - 9 2
1 - 999 (Entry of 20 15
corresponds to
100,000mm.)
1 - 999 (Entry of 20 15
corresponds to
100,000mm.)
0 - 999 20
0 - 6 0 5
1 - 5
6
1 - 255 40
When the color 0 0
process control is
executed.
Executed 1
regardless of the
process control.
When the color 2
process control
and the K process
control are
executed.
0 - 240 0
(MINUTE)
0 - 15 1
(HOUR)
0 - 15 5
(Above)+(HOUR)
0 - 1 0 1
1
