Controller Input And Outputs
03
01
04
02
Motor identifi cation harness connector
01
Clutch interlock microswitch connector
02
Serial interface connector
03
Position sensor connector
04
10 Amps slow blow mains fuse
05
8 Axess® Pro Series 3100
05
Owner Installation Instructions
WARNING! HIGH VOLTAGE!
This unit is not user
Disconnect power supply before removing
cover. Please ensure all electrical cables
are secured clear of any moving parts.
Failure to comply may cause electrocution
resulting in serious injury or death.
fi g 02
serviceable.
