AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD
GDO-4 EasyRoller
®
ROLL UP GARAGE DOOR OPENER
Warning: It is vital for the safety of persons to
OWNERS COPY
follow all instructions. Failure to comply with the
installation instructions and the safety warnings
may result in serious personal injury and/or

Installation Instructions

property and remote control opener damage.
Please save these instructions for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GDO-4 EasyRoller and is the answer not in the manual?

Questions and answers

Summary of Contents for Automatic Technology GDO-4 EasyRoller

  • Page 1: Installation Instructions

    AUTOMATIC TECHNOLOGY AUSTRALIA PTY LTD GDO-4 EasyRoller ® ROLL UP GARAGE DOOR OPENER Warning: It is vital for the safety of persons to OWNERS COPY follow all instructions. Failure to comply with the installation instructions and the safety warnings may result in serious personal injury and/or Installation Instructions property and remote control opener damage.
  • Page 2: Important Safety Instructions

    Automatic Technology Australia Pty Ltd to the extent that such may be lawfully excluded hereby expressly disclaims all conditions or warranties, statutory or otherwise which may be implied by laws as conditions or warranties of purchase of an Automatic Technology Australia Pty Ltd Roll Up Garage Door Opener.
  • Page 3: Operation

    FEATURES Your EasyRoller Automatic Garage To store any code simply press and hold OPEN AND CLOSE DRIVE ® Door Opener has many features which the Door Code button on the opener and BUTTONS you will appreciate. The components press the transmitter button twice. Each Developed by ATA to and materials used in this Automatic...
  • Page 4: Operating Controls

    OPERATING CONTROLS 1. LIGHT CODE button (White) is 7. O/S/C button (Yellow) is used 15. P.E. INPUT is for connection of used for storing or erasing the during installation to test the Open, Stop Photo Electric Beams (optional extra) transmitter button (code) you wish to and Close cycles for the Opener.
  • Page 5 OPERATING CONTROLS LIGHT CODE BUTTON (WHITE) OPEN DRIVE BUTTON (GREEN) DOOR CODE BUTTON (BLUE) OPEN LIMIT (RED) CLOSE DRIVE BUTTON (RED) CLOSE LIMIT CAM (RED) CLOSE LIMIT LED (RED) FORCE MARGIN SET BUTTON AUTO CLOSE BUTTON (WHITE) P.E. INPUT RESET BUTTON EXTERNAL RECEIVER INPUT O/S/C BUTTON (YELLOW) O/S/C INPUT...
  • Page 6: Package Contents

    PACKAGE CONTENTS ITEM QUANTITY GDO-4 EASYROLLER DRIVE UNIT EASY ACCESS TRANSMITTER EAT-1 (NOT INCLUDED IN SOME MODELS) KEY RING TRANSMITTER PTX-4 PTX-4 WALL MOUNT BRACKET ALKALINE BATTERY A23 12V WEIGHT BARS (NOT INCLUDED IN SOME MODELS) SCREW M5x40mm (NOT INCLUDED IN SOME MODELS) HEX NUT M5 (NOT INCLUDED IN SOME MODELS) SPRING WASHER I.D 5 (NOT INCLUDED IN SOME MODELS)
  • Page 7: Before Installation

    BEFORE INSTALLATION IMPORTANT SAFETY INSTRUCTIONS FOR MINIMUM SIDE ROOM FIG. 1 INSTALLATION Warning: Incorrect installation can lead to severe injury. Follow ALL installation instructions. SIDE ROOM REQUIREMENTS Fig. 1 shows the minimum side room that is required. The distance between the edge of the door curtain and the inside of the bracket is 85mm minimum, and the distance between the edge of the door curtain and the outside of the bracket is 135mm minimum.
  • Page 8: Easy Access Transmitter

    EASY ACCESS TRANSMITTER THE EASY ACCESS TRANSMITTER FIG. 6 (Not available on some models) The Easy Access Transmitter is prepared ready for use with the battery pre-installed. Before the transmitter can be operational, the Transmitter Code has to be stored into the openers memory. To store the code please follow the instructions in Step 8.1 on page 14.
  • Page 9: Mounting The Opener

    MOUNTING THE OPENER 4. FIXING DRIVE UNIT TO THE DOOR FIG. 10 CHECK IF “U” The EasyRoller Drive Assembly can be fixed to the roll up BOLT IS TIGHT garage door in a variety of ways. Described below is one method of fixing.
  • Page 10: Setting Limits

    SETTING LIMITS 5. FIXING OF DOOR CURTAIN TO DRUM FIG. 13 WHEEL The door curtain has to be secured to the drum wheel with DRUM WHEEL suitable fasteners. 1. With the door in the fully closed position, mark the curtain (Fig.
  • Page 11 SETTING LIMITS NOTE: If the door has not reached the desired limit position by FIG. 16 more then 30mm, then it is recommended that the green limits cam be adjusted again before the green fine adjustment screw is adjusted. CLOSE LIMIT ADJUSTMENT Press in and hold the red Close button.
  • Page 12 SETTING LIMITS OPEN LIMIT ADJUSTMENT FIG. 18 Press and hold the green Open button (Fig. 18). The door should start opening. Release the Open button when the door reaches the desired open limit stop position. If the green LED (Fig. 18) is illuminated and the desired limit stop position has been reached then the limit adjustment is complete.
  • Page 13: Setting Safety Obstruction Force

    SETTING SAFETY OBSTRUCTION FORCE 7. SETTING OPEN AND CLOSE SAFETY FIG. 20 OBSTRUCTION FORCE The Safety Obstruction Force is calculated automatically and set in memory on the EasyRoller. This applies to both the Open Force and Close Force. Warning: When step 7.1 is initiated the garage door will do a full open and close cycle automatically.
  • Page 14: Coding Transmitters

    CODING TRANSMITTERS 8. STORING TRANSMITTER CODES FIG. 22 PRESS AND Make sure to connect the battery to the transmitters. The HOLD DOOR CODE memory in the openers receiver can store up to 27 different BUTTON remote control transmitters. 8.1 STORING TRANSMITTER CODE 1.
  • Page 15 CODING TRANSMITTERS 11. SETTING THE TRANSMITTER TO FIG. 25 OPERATE THE COURTESY LIGHT The transmitter can be programmed to operate the courtesy light on the door opener. 1. Press and hold Light Code button (Fig. 25). 2. Press the button on the transmitter you would like to use to switch on the light for two seconds 3.
  • Page 16: Factory Default Settings

    PE BEAM AND AUTO CLOSE 14. FITTING THE SAFETY PHOTO FIG. 28 ELECTRIC BEAM SENSOR (OPTIONAL) Locate the Photo Electric Beam (P.E.) normally closed contact type in a strategic location within doorway. We recommend 150mm above the floor level and as close as possible to the door opening, inside the garage.
  • Page 17: Door Status Indicators

    PARAMETERS & SPECIFICATIONS DOOR STATUS INDICATORS OPEN LED CLOSE LED DOOR STATUS DOOR OPENER STATE BEEPER GREEN LED YELLOW OPEN CLOSE FLASHING OPENING FLASHING CLOSING DOOR TRAVEL STOPPED FLASHING FLASHING DOOR OBSTRUCTED WHEN OPENING FLASHING BEEPS WHILE DOOR OBSTRUCTED WHEN CLOSING FLASHING DOOR IS MOVING ALTERNATING...
  • Page 18: Troubleshooting

    TROUBLE SHOOTING SYMPTOM POSSIBLE CAUSE REMEDY Switch on mains power. Door will not operate. Mains power not switched on. Remove obstruction. Door is obstructed. Unlock door or remove jam. Door is locked or motor jammed. Door requires service/repair by qualified Door tracks/hardware damaged.
  • Page 19: Spare Parts List

    SPARE PARTS LIST WHEN ORDERING SPARE PARTS PLEASE QUOTE THE ORDER CODE NUMBER TO YOUR YOUR INSTALLER/DISTRIBUTOR...
  • Page 20: Warranty And Exclusion Of Liability

    WARRANTY AND EXCLUSION OF LIABILITY Subject to all of the matter set out below, Automatic Technology Australia Pty Ltd (“ATA”) warrants for twenty four (24) months from the date of purchase (specified in the receipt sales docket) that the Garage Door Opener System contained in the accompanying packaging (the “Product”) is free of any defects in material and workmanship rendering it unmerchantable.
