Control Board Adjustments

The standard operation of the opener can be altered by editing various parameters. This section describes
the parameters and the effect they have. Use the VIEWING AND EDITING PARAMETERS PROCEDURE on
Page 15 to make changes.
Menu 2 Current Trips
Motor overload detection is provided to protect the shutter and the opener. The motor is designed to run with
full load current. For one horse power motor with the default values the opener will run with 7.4 Amps for 10
seconds before going into overload.
Parameter
Full Load Amps 0.5 HP model AX3105
Full Load Amps 1.0 HP model AX3110
100% Overload Time
Menu 3. Auto-Close Times
The Auto-Close modes automatically close the
shutter after it has been operated. To implement
this the controller starts a timer once the shutter
has reached its desired open position. The timer
then counts down and when it expires the controller
starts to close the shutter. Details about the four
Auto-Close modes follow. Automatic Technology
strongly recommend using a P.E. Beam for added
safety.
Standard Auto-Close
This mode is selected by entering a non-zero
time for the "STD Auto-Close" parameter. When
selected the shutter will Auto-Close after being
fully opened (except when the shutter has reversed
to the open position after a motor obstruction or
overload). Countdown is suspended by the P.E,
OPN or SWP input being active. The countdown is
aborted if the STP input is activated. If the shutter
is already open and the OPN or the SWP input is
activated, then the countdown will start.
P.E. triggered Auto-Close
This mode is selected by entering a non-zero
time for the "P.E. Auto-Close" parameter. This
mode is used to Auto-Close the shutter but only
after a vehicle has passed through the doorway
and triggered the P.E. input. The swipe input can
be used to clear the P.E. triggered status so that
the P.E. input must be activated again before the
countdown will start. As with the other P.E. modes,
the STP input will abort countdown and the OPN
and SWP inputs will restart the countdown if the
shutter is OPEN.
26 Axess® Pro Series 3100
Min Max
0.0 1.6
0.0 2.9
0 30
Pedestrian access Auto-Close
This mode is selected by entering a non-zero time for
the "Ped'n A/C" parameter. When selected the shutter
will Auto-Close after being opened for pedestrian access
unless it was following a reverse from an obstruction.
P.E. triggered pedestrian Auto-Close
This mode is selected by entering a non-zero time for
the "P.E. Ped'n A/C" parameter. This mode is the
same as the P.E. triggered Auto-Close mode but it only
operates during pedestrian access. As the SWP input is
not available during pedestrian access, the PED input
can be confi gured to act in a SWP mode by setting the
"PED I/P = PED SWIPE MODE" parameter to ON.
Auto-Close after obstruction
Three parameters are provided to enable the Auto-Close
feature to be activated after obstructions. Normally the
Auto-Close feature is not enabled after obstructions
for safety reasons. A P.E. Beam must be used for these
features to be activated. Three parameters are:
1.
2.
3.
Owner Installation Instructions
Default Step Unit
1.6 1 Amps
3.7 1 Amps
10 1 Sec
Auto-Close after close overload
Auto-Close after open overload
Auto-Close after power up
Menu No.
2.1
2.1
2.2
