Transmitter Editing
Editing The Store Location
This feature is only available when coding the fi rst button
of a new transmitter.
1. Press NEXT or PREV to move the cursor over Store
No. (Fig. 29)
2. Press UP or DOWN to select new Store No.
3. Press SET to confi rm or NEXT/PREV to move to
the next fi eld.
This is useful when managing transmitters using a scheme
which ties the store location to the transmitter's owner.
Selection Of ID or Serial Number Display
1. Press NEXT to navigate to Menu 1 "Code
Transmitter"
2. Press SET to enter the transmitter edit procedure.
3. Press NEXT to enter transmitter list and edit mode.
4. Press NEXT/PREV to move the cursor over the ID
fi eld.
5. Press NEXT to reveal the Serial Number
The serial number display is provided for additional
means of identifi cation. The transmitter in this example
has serial number 12345.
Editing A Character Field
1. Press NEXT or PREV to move the cursor.
2. Press UP or DOWN to scroll through and select
a new character.
3. Press NEXT or PREV to move the cursor to the next
character.
4. Repeat step 2.
5. Press SET to record changes.
The second line of the display shows a list of available
characters with the current value indicated at the cursor
position (Fig. 33).
20 Axess® Pro Series 3100
(Fig. 30).
(Fig.
(Fig. 32)
Owner Installation Instructions
14 14 I
OSC PED LGT VAC
MENU 1
Code Transmitter
31).
14
OSC PED LGT VAC
14 I
56789 AB CDEFGHIJ
14 I
56789 AB CDEFGHIJ
[No Name]
D
PRESS
PR E S S
12345
SN SN
PRESS
B B B SMITH
D
PRESS
B B SMITH
D
B
PRESS
fi g
29
fi g 30
fi g
31
fi g
32
fi g 33
