Chapter
8
Device commissioning
Contextual Sensitive
Touch Screen
Bluetooth
Handset
Quick
Loudspeaker
Access Pad
Microphones
Figure 8.1: 8082 My IC Phone set layout
The following figure illustrates the connectors on the base of each set.
8AL91217USAA - Ed. 01 - July 2018 - Installation Manual
112/216
