Subsystem / Feature Set
Connectors
Chipset APQ8096
PMIC (PM8996 &
PMi8996)
Memory 3GB LPDDR4
32 GB UFS
Connectivity Wi-Fi 2.4 GHz/
5GHz via QCA6174
– SDIO
BT 2.4 GHz via
QCA6174 – UART /
PCM
GPS via WGR7640
– SSBI Qualcomm
Proprietary Protocol
RF Interfaces 2xWLAN / BT
1x GPS
Audio Interfaces 1 x Headset Output
2 x Loud-speaker
1 x Earpiece output
Open-Q™ 820 Dev Kit User Guide

Table 3.7-1 Open-Q Hardware Features

Description
Qualcomm® APQ8096
Processor
Qualcomm® PMIC,
Companion PMIC for
APQ8096 processor
Memory POP
Primary Storage for platform.
Mainly used for storing SW
applications and user data
etc.
Wi-Fi Atheros QCA6174 Wi-
Fi + BT Combo Chip
Wi-Fi Atheros 6174
Wi-Fi + BT Combo Chip
GPS Frontend
Connect to antenna on carrier
board via coax cable
Connect to antenna on carrier
board via coax cable
Headset/ headphone output
2 x loud-speaker output
Earpiece output
Open-Q™ 820 Development Kit
Specification
Qualcomm® Kyro CPU,
quad core, 64-bit ARM V8
compliant processor,
2.2GHz
NA
Up to 1866MHz LPDDR4
POP on CPU BGA chip.
Supports via 4x16bit
channels
Toshiba UFS on board. Can
support up to 64GB. Can
have the option of using both
UFS and eMMC.
802.11a/b/g/n/ac 2.4/5.0
GHz via QCA6174 over
PCIe0.
Full 2x2 antenna
configuration
Support BT 4.1 + HS and
backward compatible with
BT 1.x, 2.x + EDR
GPS/ GLONASS/
COMPASS
2.4/ 5 GHz
GPS/ GLONASS/
COMPASS
Analog differential output
Digital output
Analog differential output
