Subsystem / Feature Set
Connectors
3 x analog MICs
3 x digital MICs
Interfaces 3 x MIPI CSI
2 x USB HS & 1 x
USB SS
1 x MIPI DSI (DSI0
& DSI1) + Touch
100-pin display
Connector
3 X PCIe
Connectors 1 x MXM SOM
connector
1 x SOM to Carrier
board to board
connector

3.7.4 SOM RF Specification for WIFI, BT, GPS

The SOM includes the following radio interfaces:
o ANT1: Wi-Fi antenna 1 + BT
o ANT2: Wi-Fi antenna 2
o WGR7640: For GPS RF Front end
Antenna 1: The antenna 1 connector is for one of the two Wi-Fi antennas as well as the single Bluetooth
antenna. Antenna connector ANT1 is connected to the carrier board antenna via a coaxial cable.
Antenna 2: The antenna 2 connector is for the second Wi-Fi antenna. This antenna connector is also
connected to a carrier board PCB antenna via a coaxial cable.
Open-Q™ 820 Dev Kit User Guide
Description
Analog MIC input
Digital MIC input
Camera Connectors
CSI0, CSI1, CSI2
1 x dual stack type A USB2.0
via USB HUB for front USB
(from USB1 line), 1 x micro
AB USB 3.0 via switch (from
USB1 line), 1 x micro B USB
2.0 (from USB2 line)
100- pin display connector.
Interfaces with Intrinysc
Display Adapter Board
PCIe 0 PCIe signal to Wi-Fi
module. PCIe 1, 2 routed out
of SOM
Connector for SOM
B2B connector for SOM and
carrier board
Open-Q™ 820 Development Kit
Specification
Analog differential input
Digital input
MIPI Alliance Specification
v1.0
USB3.1 & USB2.0
MIPI Alliance Specification
v1.01. MIPI D-PHY
Specification v0.65, v0.81,
v0.90, v1.01
PCI Express Specification,
Rev 2.1
314 pin edge connector
100 pin board to board
connector
