Domain
PCI Express Slot
Mini PCI Express Connector
WWAN SIM Card (on bottom)
CSI Camera connectors
Power Probe Header
The following sections will provide in depth information on each expansion headers and connectors on the
carrier board. The information listed below is of particular use for those who want to interface other external
hardware devices with the Open-Q™ 820. Before connecting anything to the development kit, please ensure
the device meets the specific hardware requirements of the processor.

3.8.3 Open-Q Power Specification

The Open-Q™ development kit power source connects to the 12V DC power supply jack J21. Starting from
the power jack, the 12V power supply branches off into different voltage rails via step down converters on the
carrier board and PMIC on the SOM. The SOM is powered by 3.8V via Richtek step down converter U2 on the
carrier board. To ensure the SOM is getting powered correctly, user can monitor the current going into the
SOM via the power probe header J86 (see section below).
Open-Q™ 820 Dev Kit User Guide
Description
PCI Express for external
peripheral connectivity
Mini PCI Express for external
peripheral connectivity
WWAN SIM card connector
(optional)
3 x CSI port connector with CLK,
GPIOS, CCI
3 pin power probe header
Specification
PCIe1 v2.1
Supports half card only
Supports 10W card via power
supply
Supports 25W card via ATX power
supply
PCIe1 v2.1
Can support half or full size card
4bit Mini SIM card support
Supports 3 x Camera interfaces via
three separate connectors
3 x MIPI-CSI each 4 lane
•
• External flash driver
control
Support for 3D camera
•
configuration
• Separate I2C / CCI control
MIPI Alliance Specification v1.00
for Camera Serial Interface
Sense lines connected across
0.005 Ohm resistor
Open-Q™ 820 Development Kit
Usage
supported)
To connect an Ethernet PCIe
card board to support
Ethernet.
For external mini PCIe card
For WWAN mini PCI express
cards
For connecting camera
accessories.
To measure current
consumption of µSOM
