Figure 19 Display Board Default Configuration - Intrinsyc Lantronix Open-Q 820 User Manual

JAE51-pin
Display Adaptor
J8
Connector
FWVGA Truly
LCD Display
J7
ERM8
C
DSI0
O
N
N
E
C
T
O
R
3.8.18.2 Display Panel
This LCD panel comes preinstalled on the Open-Q 820 display adaptor board (part number: 225-0100). Below
are the Panel specifications:
Resolution: 480x854
•
LCD Type: IPS
•
PCAP touch panel with cover glass
•
No of Lanes: 1 x 2 lane MIPI DSI interface via Display Board.
•
• Diagonal Length: 4.5"
• Contact sales@lantronix.com
Note: The display above when mounted on the Open-Q 820 Display Adapter is meant to work with the carrier
board. Altering the use of this LCD panel is not recommended.
Note: 225-0100 display adapter boards are currently end of life. The Open-Q 820 Display adapter board (part
number: 280-0100) has the same specifications (as described above) and pin-outs as 225-0100.
Open-Q™ 820 Dev Kit User Guide
Board
DSI0
DSI1
J1
ERM8
C
O
N
N
E
C
T
O
R

Figure 19 Display Board Default Configuration

for more information
Carrier Board
J2
ERF8
C
O
N
N
E
C
T
O
R
Open-Q™ 820 Development Kit
DSI0
DSI1
Via MXM Connector
S
O
M
40
