Graphical user interface (GUI) menu

Setup (Sound)

Use this menu to adjust the sound parameters.
■ LFE Level (Low-frequency effect level)
Use this feature to adjust the output level of the
LFE (low-frequency effect) channel according to the
capacity of your subwoofer or headphones. The LFE
channel carries low-frequency special effects which are
only added to certain scenes. This setting is effective only
when this unit decodes bitstream signals.
Control range: –20.0 to 0.0 dB
Control step: 1.0 dB
Speaker (Speaker low-frequency effect level)
Select to adjust the speaker LFE level.
Headphone
(Headphone low-frequency effect level)
Select to adjust the headphone LFE level.
Note
Depending on the settings of "Bass Out" (page 94), some
signals may not be output at the SUBWOOFER PRE OUT
jacks.
■ Dynamic Range (Dynamic range)
Use this feature to select the amount of dynamic range
compression to be applied to your speakers or
headphones. This setting is effective only when the unit is
decoding bitstream signals.
Speaker (Speaker dynamic range)
Adjusts the dynamic range compression for the speakers.
Headphone (Headphone dynamic range)
Adjusts the dynamic range compression for the
headphones.
Choice
MAX Preserves the greatest amount of dynamic
range.
STD Adjusts the dynamic range to medium.
When this unit is decoding Dolby TrueHD
signals, the dynamic range control is always
active regardless of the instruction of the
input source signals.
MIN/AUTO • MIN: Adjusts the dynamic range to
narrow when this unit is decoding
bitstream signals (except Dolby TrueHD).
• AUTO: Adjusts the dynamic range
according to the instruction of the input
source signals when this unit is decoding
Dolby TrueHD signals.
96
En
Functions
■ Parametric EQ (Parametric equalizer)
Use this feature to adjust the parametric equalizer of each
speaker.
PEQ Data Copy (Parametric equalizer data copy)
Use this feature to copy the result data of the automatic
setup to the manual configuration area. You can select the
parametric equalizer type applied to the copied result data
of the automatic setup. See page 40 for the descriptions of
each parametric equalizer type.
Choice
Flat h Manual
Copies the result of the automatic setup that
the "Flat" type parametric equalizer is
applied to.
Front h Manual
Manual Copies the result of the automatic
setup that the "Front" type parametric
equalizer is applied to.
Natural h Manual
Copies the result of the automatic setup that
the "Natural" type parametric equalizer is
applied to.
PEQ Select (Parametric equalizer type select)
Use this feature to select the parametric equalizer type that
applied to the results of the automatic setup. See page 40
for the descriptions of each parametric equalizer type.
Choice
Manual Applies the manually configured parametric
equalizer in "Setup".
Flat Applies the "Flat" type parametric equalizer.
Front Applies the "Front" type parametric
equalizer.
Natural Applies the "Natural" type parametric
equalizer.
Through Does not use the parametric equalizer.
Notes
• When you carry out the automatic setup, this unit automatically
set "PEQ Select" to "Natural".
• "Level" settings (page 94) also change corresponding to the
setting of "PEQ Select".
• This unit does not change the configurations of "Manual" even
if you perform the automatic setup.
