Graphical user interface (GUI) menu

Input Select

Use this menu to adjust the parameters of each input
source.
y
To customize the input source settings, press 0SUBMENU to
turn on the submenu after you select the input source.
Input source
SIRIUS SATELLITE
RADIO
(U.S.A. and Canada
models only)
XM
(U.S.A. and Canada
models only)
iPod
PC/MCX
NET RADIO
Rhapsody
(U.S.A. model only)
TUNER
MULTI CH
PHONO
CD
TV
MD/CD-R
BD/HD DVD
DVD
CBL/SAT
DVR
VCR
VIDEO AUX
Bluetooth
USB
90
En
Parameter
Volume Trim
Video Adjustment
Parental Lock
Volume Trim
Video Adjustment
Volume Trim
Video Adjustment
Station Search (U.S.A. model
only)
Volume Trim
Video Adjustment
Multi CH Assign
BGV
Audio Select
Decoder Mode
Volume Trim
Video Adjustment
Volume Trim
Video Adjustment
Pairing
Connect
Volume Trim
Video Adjustment
USB Select
■ Audio Select (Audio input jack selection)
Use this feature to select the type of the input jack you
want to use.
Choice
Auto Automatically selects input signals in the
following order:
(1) HDMI
(2) Digital signals
(3) Analog signals
HDMI Selects only HDMI signals. When HDMI
signals are not input, no sound is output.
Coax/Opt Automatically selects input signals in the
following order:
(1) Digital signals input at the COAXIAL
jack.
(2) Digital signals input at the OPTICAL
jack.
When no signals are input, no sound is
output.
Analog Selects only analog signals. If no analog
signals are input, no sound is output.
y
• You can also select the audio input jack by pressing CAUDIO
SELECT (or OAUDIO SEL) (page 43).
• You can set the default audio input jack select of this unit by
using "Audio Select" in "Initial Set" (page 106).
Note
This feature is not available if no digital input jack is assigned
to the selected input source in "I/O Assignment" (page 105).
"HDMI" is available only when an HDMI input jack is
assigned.
■ Decoder Mode (Decoder mode)
Use this feature to switch the decoder mode.
Choice
Auto
Automatically detects digital audio signal
input types and selects the appropriate
decoder.
DTS Activates the DTS decoder when digital
audio signals are input.
Note
"Decoder Mode" is available only when the digital audio input
jacks (HDMI, OPTICAL and/or COAXIAL) are assigned to the
selected input source.
■ Volume Trim (Volume trimming)
Use this feature to adjust the level of the signal input at
each input source. This feature is useful if you want to
balance the level of each input source to avoid sudden
changes in volume when switching between input sources.
Control range: –6.0 dB to +6.0 dB
Initial setting: 0.0 dB
y
This parameter also affects the signals output at the ZONE OUT
jacks.
