2015
Operator's
Guide
Includes
Safety, Vehicle
Maintenance Information
and
(Canada/United States)
RENEGADE
TM
500/800R/1000
WARNING
Read this guide thoroughly. It contains important safety information. Minimum recommended operator's age:
16 years old. Experienced operator only. Keep this Operator's Guide in the vehicle.
2 1 9
0 0 1
4 5 3
Original Instructions

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the can-am RENEGADE 500 2015 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for BRP can-am RENEGADE 500 2015

Summary of Contents for BRP can-am RENEGADE 500 2015

  • Page 1 2015 Operator’s Guide Includes Safety, Vehicle Maintenance Information (Canada/United States) RENEGADE 500/800R/1000 WARNING Read this guide thoroughly. It contains important safety information. Minimum recommended operator’s age: 16 years old. Experienced operator only. Keep this Operator’s Guide in the vehicle. 2 1 9 0 0 1 4 5 3 Original Instructions...
  • Page 2 DPS™ X™ Visco-Lok is a trademark of GKN Viscodrive GmbH. † vmo2015-010 en ®™ and the BRP logo are trademarks of Bombardier Recreational Products Inc. or its affiliates. ©2014 Bombardier Recreational Products Inc. and BRP US Inc. All rights reserved.

  • Page 3: Foreword

    Also, read all safety labels on your ATV SAFETY new Can-Am™ ATV. It is backed by the and watch attentively your BRP warranty and a network of autho- video. rized Can-Am dealers ready to provide This vehicle is for off road use only. It is...

  • Page 4: Safety Messages

    CAUTION Indicates a hazard the descriptions and/or specifications situation which, if not avoided, in this guide may occur. BRP reserves could result in minor or moderate the right at any time to discontinue or injury.

  • Page 5: Table Of Contents

    TABLE OF CONTENTS FOREWORD ................1 Know Before you Go .
  • Page 6 TABLE OF CONTENTS MULTIFUNCTION GAUGE (LCD) ..........70 Multifunction Gauge Description .
  • Page 7 MULTIFUNCTION GAUGE MESSAGES ........136 WARRANTY BRP LIMITED WARRANTY USA AND CANADA: 2015 CAN-AM ATV . . 138 CUSTOMER INFORMATION PRIVACY INFORMATION .
  • Page 8 TABLE OF CONTENTS _______________...

  • Page 9: Safety Information

    SAFETY INFORMATION ________ ________ SAFETY INFORMATION...

  • Page 10: General Precautions

    Even if you try to ventilate engine sories that are not approved by BRP. exhaust with fans or open windows Since these changes have not been and doors, carbon monoxide can tested by BRP, they may increase the rapidly reach dangerous levels.

  • Page 11: Special Safety Messages

    SPECIAL SAFETY MESSAGES THIS VEHICLE IS NOT A TOY AND CAN BE HAZARDOUS TO OPERATE. – This vehicle handles differently from other vehicles including motorcycles and cars. A collision or rollover can occur quickly, if you fail to take proper precautions, even during routine maneuvers such as turning and driving on hills or over obstacles.
  • Page 12 SPECIAL SAFETY MESSAGES – Always follow proper procedures for crossing the side of a hill as described in RIDING TECHNIQUES in this Operator's Guide. Avoid hills with excessively slippery or loose surfaces. Never attempt to turn the vehicle around on any hill until you have mastered the turning technique on level ground.

  • Page 13: Operation Warnings

    OPERATION WARNINGS The following warning and their format have been requested by the United States Consumer Product Safety Commission and are required to be in the Operator's Guide for all ATVs. NOTE: The following illustrations are general representations only. Your model may differ.
  • Page 14 OPERATION WARNINGS WARNING V00A1AQ POTENTIAL HAZARD Failure to follow the age recommendations for this vehicle. WHAT CAN HAPPEN A lack of respect for this age recommendation can lead to severe injury or death of the child. Even though a child may be within the age group for which this vehicle is recommended, he may not have the skills, abilities, or judgment needed to operate this vehicle safely and may be involved in a serious accident.
  • Page 15 OPERATION WARNINGS WARNING V00A02Q POTENTIAL HAZARD Carrying a passenger on this vehicle. WHAT CAN HAPPEN Greatly reduces your ability to balance and control this vehicle. Could cause an accident, resulting in harm to you and/or your passenger. HOW TO AVOID THE HAZARD Never carry passenger.
  • Page 16 OPERATION WARNINGS WARNING V00A2DQ POTENTIAL HAZARD Allowing passenger to sit in any location on this vehicle. WHAT CAN HAPPEN Allowing a passenger could: – Impair vehicle stability which could lead to a loss of control. – Result in injury to passenger from impact on hard surfaces. –...
  • Page 17 OPERATION WARNINGS WARNING POTENTIAL HAZARD Operating this vehicle on public streets, roads or highways. WHAT CAN HAPPEN You can collide with another vehicle. HOW TO AVOID THE HAZARD Never operate this vehicle on any public street, road or highway, even a dirt or gravel one.
  • Page 18 OPERATION WARNINGS WARNING POTENTIAL HAZARD Riding this vehicle without wearing an approved helmet, eye protection and protective gear. WHAT CAN HAPPEN – Riding without an approved helmet increases the chances of a severe head injury or death in the event of an accident. –...
  • Page 19 OPERATION WARNINGS WARNING V00A07Q POTENTIAL HAZARD Using this vehicle with drugs or alcohol. WHAT CAN HAPPEN Could seriously affect your judgment. Could cause you to react more slowly. Could affect your balance and perception. Could result in an accident or death. HOW TO AVOID THE HAZARD Never use this vehicle with drugs or alcohol.
  • Page 20 OPERATION WARNINGS WARNING V00A08Q POTENTIAL HAZARD Operating this vehicle at excessive speeds. WHAT CAN HAPPEN Increases your chances of losing control of the vehicle, which can result in an accident. HOW TO AVOID THE HAZARD Always travel at a speed which is appropriate for the terrain, visibility and operating conditions, and your experience.
  • Page 21 OPERATION WARNINGS WARNING POTENTIAL HAZARD Attempting wheelies, jumps and other stunts. WHAT CAN HAPPEN Increases the chance of an accident, including an overturn. HOW TO AVOID THE HAZARD Never attempt stunts, such as wheelies or jumps. Do not try to show off. WARNING POTENTIAL HAZARD Failure to inspect the vehicle before operating.
  • Page 22 OPERATION WARNINGS WARNING POTENTIAL HAZARD Riding on frozen waterways. WHAT CAN HAPPEN Breaking through the ice can lead to severe injury or death. HOW TO AVOID THE HAZARD Never ride this vehicle on a frozen surface before you are sure the ice is thick enough and sound enough to support the vehicle and its load, as well as the force that is created by a moving vehicle.
  • Page 23 OPERATION WARNINGS WARNING POTENTIAL HAZARD Failure to use extra care when operating this vehicle on unfamiliar terrain. WHAT CAN HAPPEN You can come upon hidden rocks, bumps, or holes, without enough time to react. Could result in the vehicle overturning or loss of control. HOW TO AVOID THE HAZARD Go slowly and be extra careful when operating on unfamiliar terrain.
  • Page 24 OPERATION WARNINGS WARNING POTENTIAL HAZARD Failure to use extra care when operating on excessively rough, slippery or loose terrain. WHAT CAN HAPPEN Could cause loss of traction or vehicle control, which could result in an acci- dent, including an overturn. HOW TO AVOID THE HAZARD Do not operate on excessively rough, slippery or loose terrain until you have learned and practiced the skills necessary to control this vehicle on...
  • Page 25 OPERATION WARNINGS WARNING POTENTIAL HAZARD Turning improperly. WHAT CAN HAPPEN Vehicle could go out of control, causing a collision or an overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for turning as described in this Operator's Guide. Practice turning at low speeds before attempting to turn at faster speeds.
  • Page 26 OPERATION WARNINGS WARNING POTENTIAL HAZARD Operating on excessively steep hills. WHAT CAN HAPPEN The vehicle can overturn more easily on extremely steep hills than on level surfaces or small hills. HOW TO AVOID THE HAZARD Never operate this vehicle on hills too steep for the vehicle or for your abili- ties.
  • Page 27 OPERATION WARNINGS WARNING POTENTIAL HAZARD Climbing hills improperly. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for climbing hills as described in this Op- erator's Guide. Always check the terrain carefully before you start up any hill.
  • Page 28 OPERATION WARNINGS WARNING POTENTIAL HAZARD Going down a hill improperly. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Always follow proper procedures for going down hills as described in this Operator's Guide.
  • Page 29 OPERATION WARNINGS WARNING POTENTIAL HAZARD Improperly crossing hills or turning on hills. WHAT CAN HAPPEN Could cause loss of control or cause vehicle to overturn. HOW TO AVOID THE HAZARD Never attempt to turn the vehicle around on any hill until you have mastered the turning technique as described in this Operator's Guide on level ground.
  • Page 30 OPERATION WARNINGS WARNING POTENTIAL HAZARD Stalling, rolling backwards or improperly dismounting while climbing a hill. WHAT CAN HAPPEN Could result in vehicle overturning. HOW TO AVOID THE HAZARD Use proper gear and maintain steady speed when climbing a hill. If you lose all forward speed: Keep your weight uphill.
  • Page 31 OPERATION WARNINGS WARNING POTENTIAL HAZARD Improperly operating over obstacles. WHAT CAN HAPPEN Could cause loss of control, or a collision. Could cause the vehicle to overturn. HOW TO AVOID THE HAZARD Before operating in a new area, check for obstacles. Never attempt to ride over large obstacles, such as large rocks or fallen trees.
  • Page 32 OPERATION WARNINGS WARNING POTENTIAL HAZARD Skidding or sliding improperly. WHAT CAN HAPPEN You may lose control of this vehicle. You may also regain traction unexpectedly, which may cause the vehicle to overturn. HOW TO AVOID THE HAZARD Learn to safely control skidding or sliding by practicing at low speeds and on level smooth terrain.
  • Page 33 OPERATION WARNINGS WARNING POTENTIAL HAZARD Operating this vehicle through deep or fast flowing water. WHAT CAN HAPPEN Tires may float, causing loss of traction and loss of control, which could lead to an accident. HOW TO AVOID THE HAZARD Never operate this vehicle in fast flowing water or in deep water. Check water depth and current before you attempt to cross any water.
  • Page 34 OPERATION WARNINGS WARNING POTENTIAL HAZARD Improperly operating in reverse. WHAT CAN HAPPEN You could hit an obstacle or person behind the vehicle, resulting in serious injury. HOW TO AVOID THE HAZARD When you select reverse gear, make sure there are no obstacles or people behind the vehicle.
  • Page 35 OPERATION WARNINGS WARNING POTENTIAL HAZARD Operating this vehicle with improper tires, or with improper or uneven tire pressure. WHAT CAN HAPPEN Use of improper tires on this vehicle, or operation of this vehicle with improper or uneven tire pressure, may cause loss of control, tire blow outs, tire to move around on its rim, and increases the risk of an accident.
  • Page 36 Never modify this vehicle through improper installation or use of acces- sories. All parts and accessories added to this vehicle should be approved by BRP and should be installed and used according to instructions. If you have questions, consult an authorized Can-Am dealer.
  • Page 37 OPERATION WARNINGS WARNING POTENTIAL HAZARD Overloading this vehicle, carrying or towing cargo improperly. WHAT CAN HAPPEN Could cause changes in vehicle handling which could lead to an accident. HOW TO AVOID THE HAZARD Never exceed the stated load capacity for this vehicle including operator as well as other loads and added accessories.
  • Page 38 OPERATION WARNINGS WARNING V03M01Q POTENTIAL HAZARD Transporting flammable or dangerous material can lead to explosions. WHAT CAN HAPPEN This can cause serious injury or death. HOW TO AVOID THE HAZARD Never transport flammable or dangerous material. _______ ________ SAFETY INFORMATION...

  • Page 39: Important On-Product Labels

    IMPORTANT ON-PRODUCT LABELS Hang Tag This vehicle comes with a hang tag and labels containing important safety and emission informations. 704903318 704901107 vmo2006-005-009_en TYPICAL ________ ________ SAFETY INFORMATION...

  • Page 40: Vehicle Safety Labels

    IMPORTANT ON-PRODUCT LABELS Vehicle Safety Labels Read and understand all the safety la- bels on your vehicle. These labels are affixed to the vehicle for the safety of the operator or by- standers. The safety labels on your vehicle should be considered permanent parts of the vehicle.
  • Page 41 IMPORTANT ON-PRODUCT LABELS 704902812 LABEL 6 704902815 LABEL 2 704902941 FRONT: 41.4 kPa (6 psi) 113 kg UP TO LABEL 3 (250 lb) REAR : 41.4 kPa (6 psi) 113 kg FRONT FROM (250 lb) 41.4 kPa (6 psi) REAR 141 kg UP TO 48.2 kPa (7 psi)

  • Page 42: Compliance Labels

    IMPORTANT ON-PRODUCT LABELS Compliance Labels These labels indicate vehicle's compli- ance. CAN ICES-2 / NMB-2 POWER PUISSANCE WET WEIGHT POIDS EN ETAT DE MARCHE THIS VEHICLE IS AN ALL TERRAIN VEHICLE AND IS NOT INTENDED FOR USE ON PUBLIC ROADS. CE VEHICULE EST UN VEHICULE TOUT TERRAIN QUI N' E ST PAS DESTINÉ...

  • Page 43: Pre-Ride Inspection

    PRE-RIDE INSPECTION WARNING Perform a pre-ride inspection be- fore each ride to detect any po- tential problem that could occur during operation. The pre-ride inspection can help you monitor component wear and deteriora- tion before they become a prob- lem. Correct any problem that you discover to reduce the risk of a breakdown or crash.

  • Page 44: Pre-Ride Inspection Check List

    PRE-RIDE INSPECTION Pre-Ride Inspection Check List What to Do Before Starting the Engine (Key OFF) ITEMS TO BE ✔ INSPECTION TO PERFORM INSPECTED Fluids Check fuel, engine oil and coolant levels Brake fluid Check brake fluid level. Leaks Check for any leaks under vehicle Throttle lever Activate throttle lever several times to ensure it operates freely.
  • Page 45 PRE-RIDE INSPECTION What to Do Before Starting the Engine (Key ON) ITEMS TO BE ✔ INSPECTION TO PERFORM INSPECTED Multifunction gauge Check operation of indicator lamps in multifunction gauge (during first few seconds of key ON) Check for messages on multifunction gauge Lights Check operation and cleanliness of headlights and taillight Check operation of low and high beams...

  • Page 46: Riding The Vehicle

    RIDING THE VEHICLE To fully appreciate the pleasures and excitement of riding this vehicle, there are some basic rules and tips that you MUST follow. Some may be new to you while others may be common sense or obvious. Please take the time to study this Operator's Guide and all on-product safety SAFETY DVD labels as well as the video that came with this vehicle.

  • Page 47: Riding Gear

    RIDING THE VEHICLE Riding Gear Actual weather conditions should help you decide how to dress. Dress for the coldest weather expected. Thermal underwear next to the skin also provides a good insulation. It is important that the operator always wears the appropriate protective riding gear and apparel, including an approved helmet, eye protection, boots, gloves, a long sleeved shirt and pants.

  • Page 48: Environment

    RIDING THE VEHICLE users on the trail. Always stay to the complete right of the trail and do not zigzag to one side of the trail then the other. Be prepared to stop or pull off to the side if another trail user appears in front of you.

  • Page 49: Design Limitation

    RIDING THE VEHICLE Finally, do not pollute streams, lakes or rivers and do not modify the engine or ex- haust system, or remove any of its components. Design Limitation Although the vehicle is exceptionally rugged for its class, it is still a light vehicle by definition and its operation must be restricted to its proper purpose.
  • Page 50 RIDING THE VEHICLE Body Position To maintain proper control, it is strongly advised that you keep your hands on the handlebar and within easy reach of all controls. The same holds true for your feet on the foot pegs. To minimize the possibility of a leg or foot injury, keep your feet on the foot pegs at all times.
  • Page 51 RIDING THE VEHICLE To reduce the risk of rollovers: – Use care when turning. • Do not turn the handlebar too far or too fast for your speed and environment. Adjust steering inputs accordingly. • Slow down before entering a turn. Avoid hard braking during a turn. •...
  • Page 52 RIDING THE VEHICLE Braking Always keep both hands on handlebars and feet on foot pegs when braking. Practice braking to get familiar with the brake response. – Do it at low speed first, then increase the speed. – Practice braking in straight line at different speeds and different braking force. –...
  • Page 53 RIDING THE VEHICLE Uphill Driving Before trying to climb a hill, keep these things in mind. Hill Climbing should only be attempted by experienced operators. Start on shallow slopes. Always drive straight uphill and keep your body weight forward towards the top of the hill. Keep your feet on the footrests, shift your ATV into a lower gear and accelerate before you start to climb.
  • Page 54 RIDING THE VEHICLE Downhill Driving This vehicle can climb slopes that are steeper than it can safely descend. There- fore, it is essential to ensure that a safe route exists to descend a slope before you climb it. Decelerating while negotiating a slippery downhill slope could “toboggan” the ve- hicle.
  • Page 55 RIDING THE VEHICLE Side Hilling This is one of the most risky types of riding since it may drastically change the bal- ance of the vehicle. It should be avoided whenever possible. However, if it is nec- essary to do so , it is important that you ALWAYS keep your body weight on the up- side of the slope and be prepared to dismount on that side should the vehicle begin to topple.
  • Page 56 RIDING THE VEHICLE Crossing Water Water can be a unique hazard. If it is too deep the vehicle may “float” and topple. Check the water depth and current before you attempt to cross any water. Water should not go above the footrest. Be wary of slippery surfaces such as rocks, grass, logs, etc., both in the water and on its banks.
  • Page 57 RIDING THE VEHICLE Riding on Snow Covered Surfaces When performing the pre-ride inspection, pay special attention to locations on the vehicle where snow and/or ice accumulations may obstruct visibility of the taillight and reflectors, clog ventilation openings, block the radiator and fan, and interfere with the movement of control levers, switches and brake pedal.
  • Page 58 RIDING THE VEHICLE Riding on Sand Riding on sand, sand dunes or on snow is another unique experience, but there are some basic precautions that should be observed. Wet, deep or fine sand/snow may create a loss of traction and cause the vehicle to slide, drop off or become “bogged”...

  • Page 59: Moving Loads And Doing Work

    MOVING LOADS AND DOING WORK Working with your Vehicle Your vehicle can help you perform a number of different LIGHT tasks ranging from snow removal to pulling wood or carrying cargo. A variety of accessories are avail- able from your authorized Can-Am dealer. To prevent possible injury, follow the in- structions and warnings that accompany the accessory.
  • Page 60 MOVING LOADS AND DOING WORK Loading the Cargo Rack NOTICE When loading or unloading, do not exceed the weight limit of 90 kg (200 lb). Load cargo as low as possible – a higher load can raise the vehicle’s center of grav- ity, which can reduce stability.
  • Page 61 Be careful not to skid or slide. Pulling a Trailer (If Equipped with a Hitch) NOTICE A BRP approved rear hitch must be properly installed on the vehi- cle for hauling trailers. Riding this vehicle with a trailer substantially increases the risk of toppling, espe- cially on inclined slopes.
  • Page 62 MOVING LOADS AND DOING WORK This page is intentionally blank _______ ________ SAFETY INFORMATION...

  • Page 63: Vehicle Information

    VEHICLE INFORMATION _______________...

  • Page 64: Controls

    CONTROLS vmo2012-014-052_a 1) Throttle Lever The throttle lever is located on the RH side of the handlebar. The throttle lever controls the engine speed. To increase or maintain vehicle speed, press the throttle lever with your right thumb. To decrease vehicle speed, release the throttle lever.

  • Page 65: Lh Brake Lever

    CONTROLS 2) LH Brake Lever When released, the brake lever should automatically return to its original posi- The LH brake lever is located on the LH tion. side of the handlebar. Braking effect is proportional to the force applied on the lever. 4) Parking Brake The parking brake is located on the LH side of the handlebar.

  • Page 66: Brake Pedal

    CONTROLS To release parking brake: Squeeze brake lever. Lever lock should auto- matically return to its original position. Brake lever should return to rest posi- tion. WARNING Make sure parking brake is re- leased before operating the ve- hicle. If parking brake is left ON while riding, it may cause damage to the brake system and cause loss vmo2013-011-003...

  • Page 67: Ignition Switch And Keys

    CONTROLS NOTICE P: Park Use the low speed range to pull a trailer, carry heavy cargo, The park position locks the gearbox to go over obstacles or drive uphill and help prevent vehicle movement. downhill. WARNING 7) Ignition Switch and Always use the PARK (P) position Keys when the vehicle is not in oper-...

  • Page 68: Multifunction Switch

    CONTROLS ON with Lights WARNING When the key is turned in this position, On steep downhills, the engine the electrical system of the vehicle is speed limiter may not prevent the activated. vehicle from accelerating beyond this speed. The gauge should wake-up. The vehicle lights are turned on.
  • Page 69 CONTROLS Emergency Engine Stop Switch vmo2012-014-021_a TYPICAL — MULTIFUNCTION SWITCH 1. Low/high beam headlight switch 2. Emergency engine stop switch vmo2012-014-021_b 3. Engine start button TYPICAL 4. Override/DPS button (if applicable) 1. Emergency engine stop switch Low/High Headlight Switch This switch can be used to stop the en- gine and as an emergency control.

  • Page 70: 2Wd/4Wd Selector

    CONTROLS NOTE: To allow engine starting, the ig- While the shift lever is set to REVERSE nition switch must be in the ON or ON position. with lights position and the emergency 1. Ensure that the vehicle is stopped. engine stop button set to RUN. 2.
  • Page 71 CONTROLS The 2WD mode is engaged when the switch is pushed upwards. The vehicle is then rear wheel drive only. vmo2012-012-007_a TYPICAL 1. Selector 2. 2WD position 3. 4WD position This switch selects 2 wheel drive or 4 wheel drive mode when the vehicle is stopped and the engine is running.

  • Page 72: Multifunction Gauge (Lcd)

    MULTIFUNCTION GAUGE (LCD) The multifunction gauge is located in the gauge support. WARNING Reading the multifunction gauge display can distract from the op- eration of the vehicle, particularly from constantly scanning the envi- vmr2007-050-002_d ronment. 1. Transmission position DISPLAY FUNCTION Multifunction Gauge Description Park...

  • Page 73: Multifunction Gauge Modes

    MULTIFUNCTION GAUGE (LCD) Multifunction Gauge 5) 4WD Indicator Lamp Modes Speed Mode When this indicator is ON, it indicates In this mode, the main screen shows the 4WD system is activated. the speed of the vehicle either in km/h or in mph. 6) Low Fuel Level Indicator Lamp When this indicator is ON, it indi- cates that there is approximately 5 L...

  • Page 74: Navigating In The Lcd Gauge

    MULTIFUNCTION GAUGE (LCD) vsi2009-018-030 vsi2009-018-032 Clock Press and HOLD the selector button for 2 seconds to reset the hour meter. Shows current time. Engine Hour Meter (EH) The engine hour meter records engine running time. vmo2011-008-001 GAUGE SETUP Refer to to set current time.

  • Page 75: Gauge Setup

    MULTIFUNCTION GAUGE (LCD) – Engine revolutions per minute (RPM) – Both parameters simultaneously (combined mode). To change from one display to the other, proceed as follows. 1. Turn ignition key to ON to power-up vmr2007-050-002_c the system. 1. Selector button 2.
  • Page 76 MULTIFUNCTION GAUGE (LCD) 6. Choose hour second digit by press- ing button. 7. Choose minutes first digit by press- ing button. 8. Choose minutes second digit by pressing button. NOTE: The gauge will display the cur- rent time for 10 seconds then will re- turn to the normal display mode.

  • Page 77: Equipment

    EQUIPMENT vmo2014-010-001_a _______________...

  • Page 78: Operator's Seat

    EQUIPMENT 1) Operator's Seat 2) Footpeg The seat is designed for an operator The footpegs are located on the RH only. and LH side of the vehicle near engine. WARNING Never allow anyone to seat as a passenger on this vehicle. Seat Removal To remove the operator's seat, push its latch forward.

  • Page 79: Tool Kit

    EQUIPMENT vmo2012-014-007_a 1. Cargo area 2. Plastic eyelets vmo2014-010-002_a WARNING 1. Recovery hook MAXIMUM load for cargo area is 16 kg (35 lb). WARNING – Never carry a passenger on the rear cargo area. – Cargo must never interfere with the or reduce its ability to steer the vehicle.

  • Page 80: Fuel

    FUEL Fuel Requirements Use of fuel labeled E15 is prohibited by U.S. EPA Regulations. NOTICE Always use fresh gaso- line. Gasoline will oxidize; the re- Vehicle Fueling Procedure sult is loss of octane, volatile com- pounds, and the production of gum WARNING and varnish deposits which can damage the fuel system.
  • Page 81 FUEL WARNING If a differential pressure condition is noticed (whistling sound heard when loosening fuel reservoir cap) have vehicle inspected and/or re- paired before further operation. 4. Insert the spout into the filler neck. 5. Pour fuel slowly so that air can es- cape from the tank and prevent fuel flow back.

  • Page 82: Break-In Period

    BREAK-IN PERIOD Operation During Break-In A break-in period of 300 km (200 mi) or 10 operating hours is required for the vehicle. After the break-in period, the vehicle should be inspected by an authorized Can-Am dealer. Engine During the break-in period: –...

  • Page 83: Basic Procedures

    BASIC PROCEDURES Starting the Engine Stopping the Engine and Parking the Vehicle The shift lever must be set to PARK or NEUTRAL. WARNING NOTE: For your convenience, an over- ride mode allows the engine to be Avoid parking on steep slope as started with the shift lever in any po- the vehicle may roll away.

  • Page 84: Special Procedures

    SPECIAL PROCEDURES What to Do if Water is in the Remove the CVT drain plug located on the rear portion of the CVT cover.. It is accessible from the rear LH fender. Inspect the CVT drain plug to validate if water is present.

  • Page 85: What To Do If Vehicle Is Turned Over

    SPECIAL PROCEDURES What to Do if Vehicle is As soon as vehicle is pulled out of wa- ter, carry out the following: Turned Over – Drain CVT. See procedure in this When vehicle is turned over or stays subsection. tilted on the side, put the vehicle back on its wheel.

  • Page 86: Tune Your Ride

    TUNE YOUR RIDE WARNING Suspension adjustment could af- fect vehicle handling. Always take time to familiarize yourself with the vehicle's behavior after any suspension adjustment have been made. Suspension Adjustments Suspension adjustment and loading can have an effect on your vehicle han- vmo2013-007-015_a dling and comfort.
  • Page 87 TUNE YOUR RIDE Shock Damping Adjustments (X xc High Speed Compression Damping Models) High speed compression damping controls how the shock absorber re- Low Speed Compression Damping acts to a high suspension velocity Low speed compression damping con- (quick compression strokes, in most trols how the shock absorber reacts to cases when riding at higher speeds).

  • Page 88: Steering Assist Adjustment (Dps) (X Xc Models)

    TUNE YOUR RIDE Rebound Damping vmo2012-014-021_d TYPICAL 1. DPS button vmo2012-014-056_a 2. Check the multifunction gauge to 1. Rebound adjuster (screwdriver required) confirm the current DPS mode. Turn adjuster clockwise (H) to increase shock damping action (stiffer). Turn adjuster counterclockwise (S) to decrease shock damping action (softer).

  • Page 89: Vehicle Transportation

    VEHICLE TRANSPORTATION When transporting this vehicle, secure it to a trailer or in pickup box with suit- able tie-downs. Use of ordinary ropes is not recommended. WARNING Do not tow this vehicle behind a car or other vehicle. Use a trailer. Never tip this vehicle on end for transporting.
  • Page 90 VEHICLE TRANSPORTATION This page is intentionally blank ______________...

  • Page 91: Maintenance

    MAINTENANCE _______________...

  • Page 92: Break-In Inspection

    BREAK-IN INSPECTION BRP suggests that after 300 km (200 mi) or the first 10 hours of operation, whichever comes first, your vehicle be inspected by an authorized Can-Am dealer. The break-in inspection is very important and must not be neglected.

  • Page 93: Maintenance Schedule

    MAINTENANCE SCHEDULE Maintenance is very important for keeping your vehicle in safe operating condition. Proper maintenance is the owner's responsibility. The vehicle should be serviced as per the maintenance schedule. The maintenance schedule does not exempt the pre-ride inspection. WARNING Failure to properly maintain the vehicle according to the maintenance schedule and procedures can make it unsafe to operate.
  • Page 94 MAINTENANCE SCHEDULE EVERY 3 000 KM (2,000 MI) OR 100 HOURS OF OPERATION IN TRAIL RIDING CONDITIONS (WHICHEVER COMES FIRST) EVERY 1 500 KM (1,000 MI) OR 50 HOURS OF OPERATION IN SEVERE RIDING CONDITIONS (DUSTY OR MUDDY) OR CARRYING HEAVY LOADS CONDITION (WHICHEVER COMES FIRST) Inspect, clean and lubricate CVT drive and driven pulleys (including one-way bearing) Check gearbox oil level and condition...
  • Page 95 MAINTENANCE SCHEDULE EVERY 6 000 KM (4,000 MI) OR 200 HOURS OF OPERATION IN TRAIL RIDING CONDITIONS (WHICHEVER COMES FIRST) EVERY 3 000 KM (2,000 MI) OR 100 HOURS OF OPERATION IN SEVERE RIDING CONDITIONS (DUSTY OR MUDDY) OR CARRYING HEAVY LOADS CONDITION (WHICHEVER COMES FIRST) Check cooling system and perform a pressure test on pressure cap and cooling system Check engine coolant strength...

  • Page 96: Maintenance Procedures

    MAINTENANCE PROCEDURES This section includes instructions for Engine Air Filter Removal basic maintenance procedures. If you NOTICE Never remove or mod- have the necessary mechanical skills ify any component in the air filter and the required tools, you can per- housing.
  • Page 97 MAINTENANCE PROCEDURES 4. Rotate air filter cover counterclock- wise to remove it. NOTE: A socket wrench may be used to remove the filter cover. vmr2012-010-017_a TYPICAL - SOME PARTS REMOVED FOR CLARITY 1. Air filter housing inlet drain tube 3. Check air filter dirty chamber for cleanliness.
  • Page 98 MAINTENANCE PROCEDURES Air Filter Cleaning and Oiling Paper Filter Cleaning 1. Remove the foam filter from paper filter. 2. Tap out heavy dust from the paper filter. This will allow dirt and dust to get out of the paper filter. NOTE: Paper filter have a limited vbs2009-012-015_a life span;...

  • Page 99: Engine Oil

    MAINTENANCE PROCEDURES vmr2012-005-001_a 219700340 1. Cover position arrow 2. Locked AIR FILTER OIL (P/N 219 700 340) 3. Unlocked Install console as the reverse of re- moval. However, pay attention to the following. Align and insert studs with grommets on rear portion of console until studs engage with grommets.
  • Page 100 MAINTENANCE PROCEDURES NOTE: While checking the oil level, vi- Repeat the above procedures until sually inspect engine area for leaks. oil level reaches the dipstick's upper mark. Do not overfill. Properly tighten dipstick. Recommended Engine Oil For the summer season, use XPS 4-STROKE SYNTH.

  • Page 101: Oil Filter

    MAINTENANCE PROCEDURES vmo2012-012-058_a 1. Drain plug tmr2011-010-004_a 1. Oil filter screw Allow enough time for oil to flow out of 2. Oil filter cover 3. O-ring oil filter. 4. Oil filter OIL FIL- Replace the oil filter. Refer to Remove the oil filter and replace with a in this subsection.

  • Page 102: Engine Coolant

    MAINTENANCE PROCEDURES Remove as much deposits as you can with your hands. If water is available in proximity, try rinsing the radiating fins. If available, use a garden hose to rinse the radiating fins. CAUTION Never clean radiator with your hands when it is hot. Let vmo2008-005-002_a the radiator cool down before clean- TYPICAL...
  • Page 103 MAINTENANCE PROCEDURES vmo2012-014-019_a 1. Engine coolant reservoir vmo2014-010-003_a 1. Console NOTE: When checking level at tem- 2. Studs and grommets perature lower than 20°C (68°F), it may 11. Reinstall the seat. be slightly lower than MIN. mark. 6. Add coolant up to MAX. mark if re- Recommended Engine Coolant quired.
  • Page 104 MAINTENANCE PROCEDURES TIGHTENING TORQUE Cooling system 9 N•m to 11 N•m (80 lbf•in to 97 lbf•in) drain plug COOL- Bleed cooling system, refer to ING SYSTEM BLEEDING Cooling System Bleeding 1. Unscrew bleed screws on both front and rear cylinders. vmo2012-014-019_b 1.

  • Page 105: Muffler Spark Arrester

    MAINTENANCE PROCEDURES TIGHTENING TORQUE Gasket 4.4 N•m to 5.6 N•m (39 lbf•in to 50 lbf•in) ring 5. Add coolant until system is full up to the pressure cap seat. 6. Start engine. NOTE: Do not install pressure cap. 7. Run engine at idle until coolant fan vmo2012-012-709 turns ON.

  • Page 106: Cvt Air Filter (800R/1000)

    MAINTENANCE PROCEDURES vmo2012-014-015_a tmo2011-001-043_a 1. CVT air filter 1. Clean spark arrester Inspect mesh of spark arrester for any CVT Air Filter Cleaning damage. Replace as required. 1. Spray filter inside and out with AIR Inspect spark arrester chamber in muf- FILTER CLEANER (P/N 219 700 fler.

  • Page 107: Gearbox Oil

    MAINTENANCE PROCEDURES vmo2012-012-057_a TYPICAL - 1000 ENGINE vmo2010-004-016_a 1. Drain plug 2. Oil level plug 1. CVT air filter The oil should be level with the bottom 5. Clean inside the CVT air inlet end of the oil level hole. CVT Air Filter Installation Refill as required until gearbox oil level flows through oil level hole.

  • Page 108: Throttle Body

    MAINTENANCE PROCEDURES 2. Visually inspect throttle plate and throttle body venturi for cleanliness. 3. Clean inside throttle body using a common throttle body cleaner if necessary. Throttle Body Lubrication No lubrication is required. vmo2012-012-056_a TYPICAL - 800R ENGINE Throttle Body Cleaning 1.

  • Page 109: Throttle Cable

    MAINTENANCE PROCEDURES 6. Gently open throttle plate and hold fully open to reach all surfaces. 7. To remove residual dirt, spray cleaner on throttle plate and on bore. 8. Reinstall removed parts. Throttle Cable Throttle Cable Lubrication The throttle cable must be lubricated V07I0GY with CABLE LUBRICANT (P/N 293 600 1.
  • Page 110 MAINTENANCE PROCEDURES V07I0JY TYPICAL V07I0IY NOTE: Place a rag around the throttle Remove the throttle body side cover. cable adjuster to prevent the lubricant from splashing. Add lubricant until it runs out at throttle body end of the throttle cable. Reinstall and adjust the cable.

  • Page 111: Spark Plugs

    MAINTENANCE PROCEDURES vmo2006-007-029_a V07I010 RH SIDE — REAR CYLINDER 1. Spark plug 1. Throttle lever A. 2 mm (.079 in) Tighten lock nut and reinstall protector. With the shift lever on PARK position, start the engine. Check if the throttle cable is adjusted correctly by turning handlebar fully to the right then fully to the left.

  • Page 112: Battery

    MAINTENANCE PROCEDURES Battery Battery Installation Battery installation is the reverse of the removal procedure. CAUTION Never charge a bat- tery while installed in vehicle. NOTICE Always connect RED (+) These vehicles are equipped with a battery cable first. VRLA battery (Valve Regulated Lead Acid).
  • Page 113 MAINTENANCE PROCEDURES FRONT FUSE BOX DESCRIPTION RATING Injectors/Ignition 2WD/4WD Key Switch, Starter Solenoid Cooling Fan 25 A vmo2012-014-009_a 1. Gauge support Euro Control/clock (CE Models) Lights 30 A 15 A DC Outlet Accessories 2 15 A Fuel Pump Rear Fuse Holder Location The rear fuse holder is located under seat near battery.

  • Page 114: Lights

    MAINTENANCE PROCEDURES vmo2012-012-034_a 1. Rear fuse holder Rear Fuse Holder Identification REAR FUSE HOLDER vmo2012-014-057_a Pull out bulb. DESCRIPTION RATING Properly reinstall removed parts in the Main 30 A reverse order of their removal. Fan/Accessories 40 A Validate headlights operation. Dynamic power Headlight Beam Aiming steering (DPS)

  • Page 115: Drive Shaft Boot And Protector

    MAINTENANCE PROCEDURES vmo2012-012-062_a vmo2012-015-003_a ROTATE BULB COUNTERCLOCKWISE TYPICAL — FRONT OF VEHICLE 1. Drive shaft boots 2. Drive shaft protector Remove bulb socket from taillight. Installation is the reverse of the re- moval procedure. Drive Shaft Boot and Protector Drive Shaft Boot and Protector Inspection Visually inspect drive shaft protectors and boots conditions.

  • Page 116: Wheels And Tires

    MAINTENANCE PROCEDURES See an authorized Can-Am dealer if TIRE PRESSURE there is any play. FRONT REAR 41.4 kPa 41.4 kPa RECOMMENDED (6 PSI) (6 PSI) 34.5 kPa 34.5 kPa MIN. (5 PSI) (5 PSI) Although the tires are specifically de- signed for off-road use, a flat may still occur.
  • Page 117 MAINTENANCE PROCEDURES to ensure proper seat when in- flating. Mount the inner bead over the wheel like normal. NOTICE Mount tire from beadlock side only. 1.2 Seat tire outer bead in the shoulder of the beadlock in- ner ring and center the tire. vbs2010-007-004 TYPICAL 4.
  • Page 118 MAINTENANCE PROCEDURES tbl2011-001-068_b tbl2011-001-068_a TYPICAL - TIGHTENING SEQUENCE TYPICAL - FINAL TIGHTENING SEQUENCE NOTE: The beadlock clamp ring 9. Inflate tire to seat the inner bead on should be in contact with the bead- wheel. Always use safe practices, lock inner ring. The beadlock clamp such as a tire safety cage.

  • Page 119: Steering

    MAINTENANCE PROCEDURES 2. Tighten screws a few turns at a time to ensure even pressure on the beadlock clamp ring. NOTE: It is normal that the beadlock clamp ring flexes slightly to match the tire bead. Wheel Beadlock Gap Verification 1.

  • Page 120: Brakes

    MAINTENANCE PROCEDURES Brakes SUSPENSION GREASE SUSPENSION Brake Fluid Reservoir Level recommended GREASE Verification product (P/N 293 550 033) With vehicle on a level surface, check brake fluid in reservoirs for proper Rear Suspension Lubrication level. Lubricate rear sway bar links and pivot NOTE: A low level may indicate leaks or worn brake pads.
  • Page 121 MAINTENANCE PROCEDURES Brake Inspection CAUTION The brakes can be very hot after prolonged use of the vehicle and can cause burns. Wait for the brakes to cool down. The brake inspection, maintenance and repair should be performed by an authorized Can-Am dealer. However, verify the following between visits to your dealer: vmo2012-014-012_a...

  • Page 122: Vehicle Care

    VEHICLE CARE Post-Operation Care Non Compatible Cleaning Products When vehicle is used in salt-water en- NON-COMPATIBLE MATERIAL vironment (beach area, launching and CLEANING TYPE loading boats etc.), rinsing the vehi- PRODUCTS cle with fresh water is necessary to preserve vehicle and its components. ANY PETROLEUM Metallic parts lubrication is highly rec- BASE CLEANING...
  • Page 123 VEHICLE CARE vbs2012-006-001 SAFE FOR POLYPROPYLENE ______________...

  • Page 124: Storage And Preseason Preparation

    STORAGE AND PRESEASON PREPARATION When a vehicle is not in use for more than 4 months, proper storage is a ne- cessity. When using your vehicle after storage, a preparation is required. See an authorized Can-Am dealer to have your vehicle prepared for either storage or the preseason.

  • Page 125: Technical Information

    TECHNICAL INFORMATION ______________...

  • Page 126: Vehicle Identification

    These numbers are also required by the authorized Can-Am dealer to complete warranty claims properly. No warranty will be allowed by BRP if the engine identification number (EIN) or vehicle identification number (VIN) is removed, mutilated or altered in any way.

  • Page 127: Noise Emission Control System Regulation

    NOISE EMISSION CONTROL SYSTEM REGULATION Tampering with Noise Control Sys- tem Is Prohibited! U.S. Federal law and Canadian provin- cial laws may prohibit the following acts or the causing there of: 1. The removal or rendering inoper- ative by any person other than for purposes of maintenance, repair or replacement of any device or ele- ment of design incorporated into...

  • Page 128: Specifications

    SPECIFICATIONS ENGINE ROTAX ® 490, 4-stroke, 2 cylinders (V-twin), liquid cooled ROTAX ® 810, 4-stroke, 2 cylinders (V-twin), Engine type 800R liquid cooled ® ROTAX 1010, 4-stroke, 2 cylinders (V-twin), 1000 liquid cooled 4 valves/cylinder (mechanical adjustment), single Valve train over head camshaft (SOHC) with timing chain 82 mm (3.228 in) Bore...
  • Page 129 SPECIFICATIONS CVT TRANSMISSION (cont’d) 1600± 100RPM Engagement RPM 800R 1650 ± 100RPM 1000 GEARBOX Type Dual range (HI-LO) with PARK, neutral and reverse 500/650 High: 3.078/Low: 5.293/Reverse: 5.45 Overall gear ratio 800R High: 2.888/Low: 5.293/Reverse: 5.45 1000 High: 2.829/Low: 5.842/Reverse: 7.148 500/800R 400 ml (13.5 U.S.
  • Page 130 SPECIFICATIONS FUEL SYSTEM (cont’d) Fuel pump Type Electric (in fuel tank) Idle speed 1250 ± 50 RPM (not adjustable) Type Regular unleaded gasoline Fuel Minimum 87 Pump Posted AKI (92 RON) - Refer to FUEL REQUIREMENTS octane Fuel tank capacity 20.5 L (5.4 U.S.
  • Page 131 SPECIFICATIONS FRONT SUSPENSION (cont'd) Base Shock absorber Type X xc High Pressure Gas (HPG) with piggy back reservoir and dual speed compression damping 5 Position cam Preload adjustment Base and X xc Threaded REAR SUSPENSION Torsional Trailing arm Independent (TTI) with Suspension type external sway bar Suspension travel...
  • Page 132 SPECIFICATIONS WHEELS Renegade Cast Aluminum Type Renegade Beadlocks X xc Front 305 x 152 mm (12 x 6 (in)) Rim size Rear 305 x 191 mm (12 x 7.5 (in)) Wheel nuts torque 100 N•m ± 10 N•m (74 lbf•ft ± 7 lbf•ft) DIMENSIONS Overall length 218.4 cm (86 in)

  • Page 133: Troubleshooting

    TROUBLESHOOTING ______________...

  • Page 134: Troubleshooting Guidelines

    TROUBLESHOOTING GUIDELINES ENGINE DOES NOT TURN 1. Ignition switch is in the OFF position. – Place switch to the ON position. 2. Emergency engine stop switch. – Make sure that emergency engine stop switch is in ON position. 3. Transmission is not set on PARK or NEUTRAL. –...
  • Page 135 TROUBLESHOOTING GUIDELINES ENGINE TURNS OVER BUT FAILS TO START (cont’d) 3. Spark plug/ignition (no spark). – Check injectors/ignition fuse condition. – Remove spark plug then reconnect to ignition coil. – Check that ignition switch and/or emergency engine stop switch is/are at the ON position.
  • Page 136 TROUBLESHOOTING GUIDELINES ENGINE OVERHEATS (cont’d) 3. Cooling fan inoperative. – Check cooling fan fuse, refer to MAINTENANCE section. If the fuse is good, contact an authorized Can-Am dealer. ENGINE BACKFIRE 1. Exhaust system leakage. – Contact an authorized Can-Am dealer. 2.
  • Page 137 TROUBLESHOOTING GUIDELINES THE RPM INCREASES BUT THE VEHICLE DOES NOT MOVE 1. The transmission is on PARK or NEUTRAL position. – Select the R, HI or LO position. 2. CVT dirty or worn-out. – Contact an authorized Can-Am dealer. 3. Water in the CVT housing. –...

  • Page 138: Multifunction Gauge Messages

    MULTIFUNCTION GAUGE MESSAGES PILOT LAMP(S) MESSAGE DESCRIPTION Indicates that you have used the wrong DESS KEY NOT ignition key, use the proper key for this Check engine RECOGNIZED vehicle. It is also possible that the ignition key has a bad contact, remove and clean key. Message displayed when brake is applied for PARK BRAKE None...

  • Page 139: Warranty

    WARRANTY ______________...

  • Page 140: Brp Limited Warranty Usa And Canada: 2015 Can-Am Atv

    Except if otherwise specified, all genuine Can-Am ATV parts and accessories in- stalled by an authorized BRP dealer on a 2015 Can-Am ATV at the time of delivery are covered under this limited warranty. Without limiting the generality of the...
  • Page 141 BRP will not honor this limited warranty to any private use owner or commercial use owner if one of the preceding conditions has not been met. Such limitations are necessary in order to allow BRP to preserve both the safety of its products, and also that of its consumers and the general public.
  • Page 142 The customer must cease using the Can-Am ATV upon the appearance of an anom- aly. The customer must notify a servicing BRP dealer within three (3) days of the appearance of a defect, and provide it with reasonable access to the product and reasonable opportunity to repair it.
  • Page 143 BRP dealer and gives the coordinates of the new owner; or 2. BRP or an authorized BRP dealer receives a proof that the former owner agreed to the transfer of ownership, in addition to the coordinates of the new owner.
  • Page 144 This page is intentionally blank ______________...

  • Page 145: Customer Information

    CUSTOMER INFORMATION ______________...

  • Page 146: Privacy Information

    PRIVACY INFORMATION BRP wishes to inform you that your coordinates will be used for safety and war- ranty related purposes. Furthermore, BRP and its affiliates may use its customer list to distribute marketing and promotional information about BRP and related products.

  • Page 147: Change Of Address/Ownership

    Notifying BRP, even after the expiration of the limited warranty, is very important as it enables BRP to reach the ATV owner if necessary, like when safety recalls are initiated. It is the owner’s responsibility to notify BRP.
  • Page 148 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 149 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 150 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 151 CHANGE OF ADDRESS/OWNERSHIP ______________...
  • Page 152 CHANGE OF ADDRESS/OWNERSHIP This page is intentionally blank ______________...
  • Page 153 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 154 CHANGE OF ADDRESS/OWNERSHIP NOTES ______________...
  • Page 155 To be completed by the dealer at the time of the sale. DEALER IMPRINT AREA V00A2IL Please verify with your dealer to ensure your vehicle has been registered with BRP. While reading this Operator’s Guide, remember that: WARNING Indicates a potential hazard that, if not avoided, could result in serious...
  • Page 156 GUIDE DU CONDUCTEUR ENEGADE 500/800R/1000 / ANGLAIS FAIT AU / MADE IN CANADA U/M:P.C. ®™ AND THE BRP LOGO ARE TRADEMARKS OF BOMBARDIER RECREATIONAL PRODUCTS INC. OR ITS AFFILIATES. ©2014 BOMBARDIER RECREATIONAL PRODUCTS INC. ALL RIGHTS RESERVED. PRINTED IN CANADA.

This manual is also suitable for:

Can-am renegade 800r 2015Can-am renegade 1000 2015

Table of Contents
