COMMANDER
OPERATOR'S
GUIDE
Includes Safety, Vehicle and Maintenance
Information
Read this operator's guide thoroughly. It contains important safety information.
Minimum recommended operator age: 16 or older with a valid driver's license. Keep this op-
erator's guide with the vehicle at all times.
The removal or modification of evaporative emission-related parts on this OHRV is illegal.
Violators may be subject to civil and/or criminal penalties under California and federal law.
219002157
Series
WARNING
Original Instructions
