Instrument Panel - Textron Jacobsen HR 9016 Turbo Dealer's Manual

2 CONTROLS
2.3

INSTRUMENT PANEL ______________________________________________________

M
Y
K
Z
L
X
AA
K. Alarm System Test Switch
Used to test the alarm system. To test, turn ignition
key to RUN and press switch. An audible alarm will
sound and warning lights will come on.
L. 2WD / 4 WD Switch - Forward
Sets mower into two or four wheel drive. Mower must
be in 4WD to operate cutting units.
Mower returns to 2WD when backing up unless 4WD
reverse switch (Z) is pressed.
M. Engine Throttle
Controls engine speed. Run machine at full throttle
when transporting machine.
en-9
N. Check Engine Light
O
P
O. Deck Levers
Q
4231860
R
S
P. Traction Control
T
U
V
W
N
Q. Light Switch (optional)
R. Warning Lights
Figure 2C
S. Engine Coolant Temperature
T. Fuel Gauge
U. Hour Meter
Indicates that a fault has occurred in the engine
control system. Refer to the Parts & Maintenance
manual.
Raises and lowers decks. Decks can be raised or
lowered separately or together. When raising decks
hold lever back until deck is completely up. Levers
return to Neutral when released.
Transfers weight between decks and mower.
Turn control clockwise to reduce down
pressure on decks and transfer weight to
mower. Reducing down pressure improves
traction but may cause decks to float causing an
uneven cut.
To increase down pressure on decks turn
control counterclockwise.
traction but improves deck contact with
ground.
Controls operation of road and work lights.
Alerts the operator to conditions requiring immediate
action. See Section 2.4.
Indicates engine coolant
operating temperature should be between 160° -
230° F (71°-110° C). If temperature rises above 230°
(110° C), alarm will sound. See Section 2.4.
Indicates current fuel level. Check fuel gauge daily
before starting machine.
Records engine operating hours. Use hour meter to
schedule periodic maintenance.
This reduces
temperature. Normal
