SET-UP

3.1 GENERAL _________________________________________________________________
The set-up and testing of the unit should always be
performed by a trained technician familiar with the
operation of this equipment.
Read each instruction completely and make sure you
understand it before proceeding with the assembly. Stay
alert for potential hazards and obey all safety
precautions.
The RIGHT and LEFT, FRONT and REAR of the
machine are referenced from the operator's seat, facing
forward.
3.2

INITIAL ASSEMBLY ________________________________________________________

!
WARNING
Make sure the mower is parked on a solid and level
surface. Never work on a mower that is supported
only by the jack. Always use jack stands.
1. Check tires for proper inflation. Tires have been over
inflated for transport.
Mower: - 20-22 psi (1.38-1.52 BAR)
Deck: - 20-25 psi (1.38-1.73 BAR)
2. Check battery connections.
Make absolutely certain the ignition switch is "Off"
and the key has been removed before servicing the
battery.
!
CAUTION
Always use insulated tools, wear protective glasses or
goggles, and protective clothing when working with
batteries. You must read and obey all battery
manufacturer's instructions.
Verify battery polarity
disconnecting the battery cables.
When installing the battery, always assemble the
RED, positive (+) battery cable first, and the ground,
BLACK, negative (-) cable last.
Make sure battery is properly installed and secured
to the battery tray.
Tighten cables securely to battery terminals and
apply a light coat of silicone dielectric grease to
terminals and cable ends to prevent corrosion. Keep
vent caps and terminal covers in place.
before connecting or
Accessories, such as cutting units and ROPS, not
included with this product must be ordered separately.
See instructions provided with accessory for installation
and parts.
!
CAUTION
Do not attempt to drive the mower unless you are
familiar with this type of equipment and know how to
operate all controls correctly.
