Table Of Contents - Textron Jacobsen HR 9016 Turbo Dealer's Manual

FOREWORD
This manual contains safety and operating instructions
for your new Jacobsen machine. This manual should be
stored with the equipment for reference during operation.
Before you operate your machine, you and each operator
you employ should read the manual carefully in its
entirety. By following
maintenance instructions, you will prolong the life of your
equipment, and maintain its maximum efficiency.
If additional information is needed, contact your
Jacobsen Dealer.
The serial plate is located on the frame rail behind the
fuel tank. Jacobsen recommends you record these
numbers below for easy reference.
SAFETY
1.1 How to Operate Safely . . . . . . . . . . . . . . . . . . 2
1.2 Important Safety Notes. . . . . . . . . . . . . . . . . . 5
CONTROLS
2.1 Icons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
2.2 Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
2.3 Instrument Panel . . . . . . . . . . . . . . . . . . . . . . 9
2.4 Operator Alerts . . . . . . . . . . . . . . . . . . . . . . . 11
SET-UP
3.1General12
3.2 Initial Assembly . . . . . . . . . . . . . . . . . . . . . . 12
3.3 Front Deck . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3.4 Front Lift Limit Switch . . . . . . . . . . . . . . . . . . 13
3.5 Initial Inspection . . . . . . . . . . . . . . . . . . . . . . 14
3.6 Operating Checks. . . . . . . . . . . . . . . . . . . . . 14
3.7 Interlock System. . . . . . . . . . . . . . . . . . . . . . 15
3.8 Traction Pedal Speed Limiter . . . . . . . . . . . . 15
These are the original instructions verified by
Jacobsen, A Textron Company.
© 2012, Jacobsen, A Textron Company/Textron Innovations Inc.
"All rights reserved, including the right to reproduce this material
or portions thereof in any form."
en-1
the safety, operating,
LITHO IN U.S.A. 9-2014
CHARLOTTE, NC
and
CHARLOTTE, NC
YEAR OF
PRODUCTION:
ADJUSTMENTS
4.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
4.2 Leveling Decks . . . . . . . . . . . . . . . . . . . . . . 16
4.3 Servicing Front Deck. . . . . . . . . . . . . . . . . . 17
4.4 Winglet Adjustment . . . . . . . . . . . . . . . . . . . 17
4.5 Cutting Height . . . . . . . . . . . . . . . . . . . . . . . 18
4.6 Lift Limit Switches . . . . . . . . . . . . . . . . . . . . 19
4.7 Neutral Adjustment . . . . . . . . . . . . . . . . . . . 20
4.8 Neutral Sensing Switch . . . . . . . . . . . . . . . . 20
4.9 Forward Sensing Switch . . . . . . . . . . . . . . . 21
4.10 Parking Brake . . . . . . . . . . . . . . . . . . . . . . . 21
4.11 Parking Brake . . . . . . . . . . . . . . . . . . . . . . . 22
4.12 Traction Pedal . . . . . . . . . . . . . . . . . . . . . . . 22
4.13 Steering Toe-In . . . . . . . . . . . . . . . . . . . . . . 22
4.14 Steering Stop Bolts . . . . . . . . . . . . . . . . . . . 23
4.15 Torque Specification . . . . . . . . . . . . . . . . . . 24
LUBRICATION CHART
5.1 Lubrication Chart. . . . . . . . . . . . . . . . . . . . . 25
TROUBLESHOOTING
6.1 General . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
NOTES
PRE-DELIVERY CHECKLIST
This
chemicals known to the State of
California to cause cancer and birth
defects or other reproductive harm.
A Textron Company
PRODUCT OF U.S.A.
A Textron Company
MADE IN U.S.A.
Proposition 65 Warning
product contains or
®
®
emits
