CONTROLS

2.1

ICONS ___________________________________________________________________

Read Manual
Hour Meter
Diesel Fuel
D
Parking Brake
Coolant
Temperature
Never attempt to drive the mower unless you have read the Safety and Operation Manual
and know how to operate all controls correctly.
Familiarize yourself with the icons shown above and what they represent. Learn the
location and purpose of all the controls and gauges before operating this mower.
Deck Lift Levers
Lower Raise
Alarm Test Switch
Test Off
Lights
Road Work
Power Take-off
Off On
Weight Transfer
to Decks
Increase Decrease
!
Engine Throttle
High Low
Decks
Raise Lower
Cruise Control
Lock Unlock
Engine
Off Run Start
Warning Lights
Hydraulic
Engine Oil
Oil Level Pressure
WARNING
CONTROLS
Decks
Left Center
Drive
Forward Reverse
2WD 4WD 4WD
Travel
Forward Reverse
Hydraulic Battery
Oil Filter Charge
2
Right
