Controls - Textron Jacobsen HR 9016 Turbo Dealer's Manual

2

CONTROLS

A
Tilt Steering
B1
Turn Assist - Left
B2
Turn Assist - Right
C
Speed Limiter
D1
Traction Pedal -Forward
D2
Traction Pedal - Reverse
E
Alarm
F
Hydraulic Oil Cap/Dipstick
G
Fuel Cap
H
Parking Brake
I
Seat Adjustments
J
Side Deck Transport Locks
K
Alarm System Test Switch
L
2WD / 4WD Switch - Forward
M
Engine Throttle
I
H
G
J
en-7
N
Check Engine Light
O
Deck Lift/Lower Levers
P
Traction Control
Q
Light Switch
R
Warning Lights
S
Engine Coolant Temperature
T
Fuel Gauge
U
Hour Meter
V
Ignition Switch
W
Hyd. Oil Level Light
X
Cruise Control (Option)
Y
Power Take-off Switch
Z
2 WD / 4WD - Reverse
AA
Panel Latch
B
B
1
2
A
C
D
1
D
2
M
E
Y
K
F
Z
L
X
AA
O
P
Q
4231860
R
S
T
U
V
W
N
HR001
Figure 2A
