Chapter 2
Installation and Wiring
This chapter will cover:
Section 2.1
Compliance to
European
Union Directives
This product is approved for installation within the European Union and EEA
regions. It has been designed and tested to meet the following directives.

2.1.1 EMC Directive

The 2085-IT8/IT16-SC modules are tested to meet Council Directive
2014/30/EU Electromagnetic Compatibility (EMC) and the following standards,
in whole or in part, documented in a technical construction file:
Section 2.2
Power
Requirements
WARNING
The modules receive power through the bus interface from the +5 VDC/+24
VDC system power supply, and a 24 VDC field power supply. Both must be
present for the modules to operate.
Compliance to European union directives
Power requirements
General considerations
Mounting
Field wiring connections
IEC 61000-6-4 Electromagnetic compatibility (EMC)–Part 6-4: Generic
standards–Emission standard for industrial environments
IEC 61000-6-2 Electromagnetic compatibility (EMC)–Part 6-2: Generic
standards–Immunity for industrial environments
EN 61131-2 Programable controllers–Part 2: Equipment requirements
and tests
The backplane power and the analog inputs of the device shall only be
supplied by an Isolated Secondary Limited Energy Low Voltage source.
User's Manual Pub. 0300322-01 Rev. A
