ADC
Filter
Selection
17 Hz
4 Hz
62 Hz
470 Hz
ADC
Filter
Selection
17 Hz
62 Hz
470 Hz
Fault Code Extended Fault Code
0×302
0×303
xF29z*
0×304
*: z indicates the slot number of the expansion I/O. If z=0, then the slot number cannot be
identified.
Chapter 3: Configuring the 2085-IT8-SC/IT-16-SC Using CCW
data ready for channel CJ compensation, these bits will be cleared, and the
channel input reading will be resumed.
Estimated channel scan rates are:
MUX/PGA ADC
Settling Conversion
Time Time
10 121
10 481
10 33
10 5
NOTE:
•
All timing units are in ms.
•
*: Channel configuration setup for 1 measurement only. This applies to
all Input Types.
•
The second measurement on open circuit detection occurs every 3
seconds which will take 23 ms per enabled channel.
Module update rate is proportional to the channels enabled and it is also affected
by the open circuit detection enable bits. The following table indicates maximum
module date rate with all channels enabled, and all channel open circuit detection
bits enabled.
Scan Rate Number of
Per Channels
Channel
139 + 23
4 Hz 499 + 23
51 + 23
23 + 23

3.9.1 Module Specific Hardware Errors

A Micro850 or 870 PLC can generate a series of 0×F2xy error codes specific to
an Expansion I/O module. The Fault code is 0×F29z, where z indicates the slot
number of the expansion I/O. If z=0, then the slot number cannot be identified.
Example error captured below.
MCU
Total Channel Scan Rate
Processing
Measurement per
Overhead
8
8
8
8
Total Module Scan Rate
16 1296
16 4176
16 592
16 368
Combined Error Description
0×302 MCU board power brownout
0×303 Unused
A/D Converter Communication Error.
Module detects the analog-to-digital
0×304
converter is not functioning properly
during data acquisition.
User's Manual Pub. 0300322-01 Rev. A
Channel*
139
499
51
23
3-33
