Spectrum Controls Micro800 2085-IT8-SC User Manual page 15

Input Specifications
Fault detection
Wire Installation
Wire size
Wire Strip Length
Recommended Tightening
Torque:
Module Dimensions
Environmental Tests
Temperature (Operating)
(Performance Criteria A)
Temperature
(Non-operating)
(Performance Criteria B)
Humidity (Operating)
(Performance Criteria A)
Vibration (Operating)
(Performance Criteria A)
Shock (Operating)
(Performance Criteria A)
Shock (Non-operating)
(Performance Criteria B)
Radiated Emissions
Conducted Emissions
ESD immunity
(Performance Criteria B)
Over/under range for all types
Open Circuit detection
Note: Thermocouple open circuit (open wire) will be
periodically checked using the PGA burnout current. This
saves on component cost and increases the Voltage Input
impedance.
#16 to #28 AWG
0.375 in.
0.25 N-m (2.2 in-lbs.)
110 mm × 87 mm × 51 mm (plastic only).
(4.33 in × 3.43 in × 2.00 in)
110 mm × 89 mm × 51 mm (with RTBs installed).
(4.33 in × 3.5 in × 2.00 in)
(CJC adds additional height beyond this)
Table 1-2. Environmental Specification Table
Test Limits
-20 ºC to 65 ºC (-4 ºF to 149 ºF)
-40 ºC to 85 ºC (-40 ºF to 185 ºF)
5 to 95% non-condensing
2 G at 10 to 500 Hz, 0.030 in. max. peak-to-peak
25 G, 11 ms half-sine (3 mutually perpendicular axes)
25 G (35 G Panel mount), 11 ms half-sine (3 mutually
perpendicular axes)
(Enclosure) Class A, 30 MHz – 1 GHz
Group 1, Class A (AC Mains), 150 kHz – 30 MHz
6 kV Indirect (Coupling Plate)
6 kV Contact Discharge (to points of initial contact)
8 kV Air Discharge (to points of initial contact)
Chapter 1: Module Overview
Value
User's Manual Pub. 0300322-01 Rev. A
1-7
