Chapter 1
Module Overview
This chapter covers the following topics:
The Micro800
Module (2085-IT8/IT16-SC Expansion I/O Module) is an 8/16 point
thermocouple input module for use in Rockwell's Micro850 and Micro870
Systems over its Expansion I/O buses. The minimum system requirement in
which an Expansion I/O Module can be installed is a Micro850 or Micro870
Controller and a controller power supply.
Section 1.1
General
Description
NOTE
General description
Input Specifications
Data formats
Hardware features
System overview
TM
8/16-Channel Thermocouple and Millivolt Analog Input
The module firmware released as revision 1.1 is compatible with the
Micro850 Series A & B PLCs and Micro870 Series A PLC with its PLC
firmware revision 11.011 and under. The number of 2085-IT16-SC
modules or 2085-IT8-SC modules that can be loaded with a Micro850/870
PLC is based on the PLC model and memory. The number may vary
between controller firmware revision and different CCW software
revisions
User's Manual Pub. 0300322-01 Rev. A
