Spectrum Controls Micro800 2085-IT8-SC User Manual page 13

Input Specifications
Type K (-270C to -170C)
Type E (-190C to 1000C)
Type E (-270C to -190C)
Type S (0°C to 1768.1°C)
Type R (0°C to 1768.1°C)
Type B (300°C to 1820°C)
Type C (0°C to 2315°C)
CJC Sensor Range
CJC Profile accuracy
CJC Sensor accuracy
CJC Measurement accuracy
CJC Total accuracy (Sum of
three items above)
Voltage accuracy
Specifications only apply to 4
Hz and 17 Hz filters
±50 mV
±100 mV
Repeatability (at 25 ºC)
Thermocouples
Type J (-210 C to 1200 C)
Type N -100 C to 1300 C)
Type N (-210 C to -100 C)
Type T (-170 C to 400 C)
Type T (-270 C to -170 C)
Type K (-170 C to 1370 C)
Type K (-270 C to -170 C)
Type E (-190 C to 1000 C)
Type E (-270 C to -190 C)
1
These filters do not reject 50/60 Hz. Repeatability for these filters is strongly dependent on how much 50/60Hz noise is in the
system.
Chapter 1: Module Overview
±6.0 C, ±15.0C
±0.4 C, ±0.6 C
±3.0 C, ± 6.0C
±1.0 C, ± 2.0 C
±1.0 C, ±2.0 C
±1.8 C, ±4.0 C
±0.8 C, ±1.8 C
-20 ºC to 90 ºC
±2.1 ºC maximum (Correlation between reading and target
terminal)
±0.2 ºC maximum (for 0 ºC to 70 ºC input values)
±0.4 ºC maximum (for full -20 ºC to 90 ºC CJC input values)
±0.2 ºC maximum (for 0 ºC to 70 ºC input values)
±0.5 ºC maximum (for -20 ºC to 90 ºC input values)
±2.5 ºC maximum (for 0 ºC to 70 ºC input values)
±3.0 ºC maximum (for full -20 ºC to 90 ºC CJC input values)
Error at 25 ºC, Max
±20 uV
±20 uV
4 Hz filter 17 Hz filter
±0.2 °C ±0.4 °C
±0.2 °C ±0.2 °C
±0.2 °C ±0.3 °C
±0.2 °C ±0.2 °C
±0.5 °C ±0.6 °C
±0.2 °C ±0.4 °C
±2 °C ±3.5 °C
±0.2 °C ±0.4 °C
±1 °C ±1.5 °C
User's Manual Pub. 0300322-01 Rev. A
Value
±7.0 C, ±20.0 C
±0.5 C, ±1.2 C
±3.5 C, ±10.0 C
±1.2 C, ±2.6 C
±1.2 C, ±2.6 C
±2.1 C, ± 4.5 C
±1.0 C, ±4.0 C
Error over -20 ºC to 65 ºC, Max
±50 uV
±100 uV
60 and 470 Hz filters
±3 °C
±4 °C
±7.5 °C
±3.3 °C
±20 °C
±3.8 °C
±20 °C
±2.4 °C
±20 °C
1-5
