1-8
Chapter 1, Module Overview
Environmental Tests
Radiated RF immunity
(Performance Criteria A)
EFT/B immunity
(Performance Criteria B)
Surge transient immunity
(Performance Criteria B)
Conducted RF immunity
(Performance Criteria A)
Magnetic Field
(Performance Criteria A)
AC Mains Voltage Dips, Interruptions
and Variations
Safety Tests
UL Safety
UL Hazardous
Locations
CE EMC Directive
User's Manual Pub. 0300322-01 Rev. A
Test Limits
10 V/M with 200 Hz square-wave 50% Pulse 100% AM at 900
& at 1890 MHz
10 V/M with 1 kHz sine-wave 80% AM from 80...2000 MHz
3 V/M with 1 kHz sine-wave 80% AM from 2000...6000
MHz (10 V/M goal)
Signal Ports:
±2 kV at 5 kHz for 5 minutes, Criteria B
Power Ports:
±2 kV at 5 kHz for 5 minutes, Criteria B
Signal Ports:
±2 kV line-earth {CM} at 2 Ω on shielded ports
Power Ports
±2 kV CM at 12 Ω
±1 kV DM at 2 Ω
10 VRMS with 1 kHz sine wave 80% AM from 150 kHz...80
MHz on signal and power ports
30 Arms/m
Follow the 61000-4-11.
Table 1-3. Safety Test Specification Table
Industry Standards
UL 61010-2-201 Safety Requirements for Electrical Equipment for
Measurement, Control, and Laboratory Use - Part 2-201: Particular
Requirements for Control Equipment (NRAQ, NRAQ7)
cUL CAN/CSA C22.2 No. 61010-1-12 (Safety Requirements for Electrical
Equipment for Measurement, Control,
and Laboratory Use – Part 1: General Requirements)
ULH ANSI/ISA–12.12.01–2007 Nonincendive Electrical Equipment for Use
in Class I, Division 2 Hazardous (Classified) Locations (NRAG)
cULH CSA C22.2 No. 213-M1987 - Non-incendive Electrical Equipment for
use in Class I Division 2 Hazardous Locations - March 1987 (NRAG7)
Temp code T5, Pollution degree 2, gas groups a, b, c, & d
IEC 61131-2 Programmable Controllers: Third Edition 2007-02, Clause 8
IEC 61000-6-2: Generic Industrial Immunity
IEC 61000-6-4: Generic Industrial Emissions
