2-10
Chapter 2: Installation and Wiring
RTB1
Name
Description
15
IN7+
Ch7 Positive input
16
IN7-
Ch7 Return
CJC 1 Positive Input
17
CJC1+
(Potted thermistor on this side)
18
CJC1-
CJC 1 Return
User's Manual Pub. 0300322-01 Rev. A
RTB2
Name
Description
33
IN14+
Ch14 Positive input
34
IN14-
Ch14 Return
35
IN15+
Ch15 Positive input
36
IN15-
Ch15 Return
