Swing-away
lattice in lattice
construction
2
The distances are always measured from the centre of the fork elements.
5960 mm (234.6 in)
4670 mm (183.8 in)
3940 mm (155.1 in)
I
n
t
e
g
r
a
2950 mm (116.1 in)
t
e
d
1)
The dimensions apply to the derricking swing-away lattice.
For the inclinable swing-away lattice, the centres of gravity are about
100 mm (4.0 in) further in front.
