Maintenance
9.4 Description of the maintenance work
On auxiliary sin-
gle-sheave boom
top and heavy
load lattice exten-
sion
9.4.2
Grease, spare
parts and tools
Prerequisites
9 - 6
– Pins for the section 3 and section 4 connections;
– Pins on the deflection sheave;
– Lubricate the pins for the connections on the left and right of the main
boom head.

Lubricate joints

The following table holds only for GMK 5095:
1)
Grease Designation
per DIN 51502
Grease
à
1)
Lubricant list and lubricant use Maintenance manual GMK 5095
– Grease gun
Designation
No spare parts
– The truck crane must be secured to prevent unauthorised use;
à
Maintenance manual of the truck crane delivered, or:
– swing-away lattice is removed;
à
p. 4 - 18.
Specification
Classification
KP - L2K DIN 51825
à
p. 3 - 10.
3 112 441 en
à
p. 4 - 9.
part no.
00554201
Quantity GROVE part no.
Lattice extension operating instructions
GMK 4100/4100-L/5095
