Validity
– 3 112 298
– 3 112 374
– 3 112 465
Reasons for the
additional infor-
mation
Additional pages GMK 4100
Driving with a rigged crane
These additional pages are valid for all truck cranes GMK 4100 with the Lat-
tice extension operating manual with one of the following identification num-
bers:
– 3 112 327
– 3 112 436
– 3 112 466
Swing-away lattice and boom extension
The values for the tables Driving with rigged crane are available.
Integrated heavy load lattice extension: altered procedure
The specifications in the supplied Lattice extension operating instructions in
the chapter Driving with rigged crane in the section Integrated heavy load lattice
extension (ISS) are not applicable. Proceed as follows:
– The rigging modes and axle loads specified in these additional pages are
à
Integrated heavy load lattice extension: ISS-A or ISS-B , p. 9.
valid;
•
To move the crane on site, enter the SLI code for the current working
position with ISS in accordance with the lifting capacity table.
•
Move the main boom and the lattice extension into the prescribed
position.
Auxiliary single-sheave boom top and heavy load lattice extension
The specifications in the delivered Lattice extension operating instructions
in the chapter Driving with rigged crane for auxiliary single-sheave boom top
remain or heavy load lattice extension remain valid.
