Centre of gravity of the swing-away lattice
Validity
Slinging
Additional pages
GMK 4100, GMK 4100-L, GMK 5095
Additional pages
These additional pages apply to the GMK 4100, GMK 4100-L and GMK 5095
mobile cranes without connection eyes (1) on the swing-away lattice.
•
Sling the swing-away lattice for the current rigging mode at the centre of
gravity displayed.
– Swing-away lattice in lattice construction;
– Swing-away lattice in box construction,
– S wing-away lattice with integrated heavy load lattice extension (ISS);
à
p. 4
The dimensions can differ slightly because of deviations due to manufacturing.
•
Raise the swing-away lattice a little first and check that the centre of gravity
is correct.
•
Correct the centre of gravity if necessary.
3 112 620 en
à
p. 2
à
p. 3
s
1
