Figure 15. Attaching the pole-mount box
Find the mounting brackets that were included in the package
1
and attach them to the back of the Standard Preassembled
Cabinet.
Use Band-It or a similar clamping system to attach the Standard
2
Preassembled Cabinet to the pole.
Figure 16. Connecting power cable to terminal blocks
Insert the power cable through the leftmost cable grip on the
3
bottom of the box. Twist the cable grip to tighten.
Insert the black conductor into the round hole on the plug por-
4
tion of the L terminal block. Insert a small screwdriver into the
L
L
N
G G
Chapter 3: Installing Power, Surge Protection, and Communications 
Lightning
Surge
Protection
W
Click!
200
+DC
-DC
GND
485-
485+
GND
RTS
CTS
TD
RD
GND
GND
 23
