A. Specifications
This appendix describes the electrical, environmental, and mechanical specifications of the
ZT 5504. It includes connector descriptions and pinouts, as well as illustrations of the board
dimensions and connector locations.
Electrical and Environmental
The topics listed below provide tables and illustrations showing the following electrical and
environmental specifications:
• Absolute maximum ratings
• DC operating characteristics
• Battery backup characteristics
Absolute Maximum Ratings
The values below are stress ratings only. Do not operate the ZT 5504 at these maximums. See
the
"DC Operating
Supply Voltage, Vcc:
Supply Voltage, Vcc3:
Supply Voltage, AUX +:
Supply Voltage, AUX -:
Storage Temperature (no hard disk):
Storage Temperature (with hard disk):
Non-Condensing Relative Humidity:
DC Operating Characteristics
Supply Voltage, Vcc:
Supply Voltage, Vcc3:
Supply Voltage, AUX +:
Supply Voltage, AUX -:
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
Characteristics" section in this appendix for operating conditions.
4.85 minimum to 5.25V maximum
3.20 minimum to 3.47V maximum
10.8 minimum to 13.2V maximum
-13.2 minimum to -10.8V maximum
6.5V
4.5V
15V
-15V
-40° to +85° Celsius
-40° to +65° Celsius
<95% at 40° Celsius
53
