3. Configuration

The ZT 5504 has been designed for maximum flexibility. Many features can be configured by
the user for specific applications. Most configuration options are selected through the BIOS
Setup utility (discussed in the
cannot be software controlled and are configured with switches or cuttable traces. Switch
options are made by closing or opening the appropriate switch. Cuttable trace options are
made by installing or removing surface mount zero Ω resistors.

Switch Options and Locations

The ZT 5504 contains a push-button switch on the faceplate and three banks of DIP switches
on the component side of the board. The switches are listed and briefly described in the
"Switch Cross-Reference" table below.
Factory default switch settings are shown in the
Note: Where switches are referenced in this chapter, "SWx" refers to the switch number and "-N" refers
to the switch segment (SW4-2 means "switch number 4, segment 2").

Switch Cross-Reference Table

Switch
Function
SW1
Reset (push-button on faceplate)
SW2-1
Battery-back Real-Time Clock
SW2-2
Clear Real-Time Clock
SW2-3
Enable VGA Routing to Rear Panel
SW2-4
Reserved
SW3-1
BIOS Recovery Module/Flash Select
SW3-2
Flash Write-Protect
SW3-3
IPMI Flash Write Protect
SW3-4
Drone Mode Reset
SW4-1
User Software Configuration 0
SW4-2
User Software Configuration 1
SW4-3
User Software Configuration 2
SW4-4
Console Redirection
