Supply Current, Icc:
Supply Current, Icc3:
Supply Current, AUX + (12V):

Battery Backup Characteristics

Battery Voltage:
Battery Capacity:
Real-Time Clock Requirements:
Real-Time Clock Data Retention:
Electrochemical Construction:
CAUTION:
There is a danger of explosion if the battery is incorrectly replaced or handled. Do not
disassemble or recharge the battery. Do not dispose of the battery in fire. When the battery is
replaced, the same type or an equivalent type recommended by the manufacturer must be
used. Used batteries must be disposed of according to the manufacturer's instructions.
Return the board to Intel for battery service.

Operating Temperature

The ZT 5504's heatsink allows a maximum ambient air temperature of 50°C with 200 LFM
(linear feet per minute) of airflow. External airflow must be provided to the ZT 5504 at all times.
Refer to the "Electrical and
refer to the topic "Temperature
on monitoring the processor temperature.

Reliability

MTBF: 14.6 years (excluding on-board hard disk drive)
MTTR: 3 minutes (based on board replacement), plus system startup
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com
4A average (typical with 850 MHz processor and
512 MB SDRAM. Peak (short duration) power
supply current may be significantly higher (up to
50%) and will vary depending upon the application.
6A average (typical with 850 MHz processor and
512 MB SDRAM. Peak (short duration) power
supply current may be significantly higher (up to
50%) and will vary depending upon the application.
50mA maximum
3V
250mAh
8µA maximum (Vbat = 3V, Vcc=0V)
31,250 hours / 3.7 years minimum (not
powered); 5.2 years minimum (with Vcc power
applied 8 hours per day)
Long life lithium with solid-state polycarbon
monofluoride cathode.
The ZT 5504 contains a lithium battery. This battery is not field-replaceable.
Environmental" topic in Chapter 2 for additional information. Also
Monitoring" in Appendix B, "Thermal Considerations", for details
A. Specifications
