Control Functions
• CPU board Reset Control
• CPU board power on/power off control
• CPU NMI Assertion to processor
• Dual Domain Mode (TBD)

BMC LED Control

The BMC controls the following status LED pins:
LED0 FP_BMC_BLUE_LED-
LED1 RP_BLUE_LED-
LED2 Health LED (normal - green)
LED3 Health LED (needs attention - amber)
LED4 Not used
LED5 Not used

Field Replaceable Unit Information

The BMC controller monitors Field Replaceable Unit (FRU) information for the ZT 5504 and a
rear panel I/O board (if present). Each device has its own address.

System Event Log Information

The BMC controller stores system event information in an 8K x 8 serial EEPROM device. Both
the in-band KCS interface and the out-of-band IPMB interface provide access to the System
Event Log (SEL). This allows SEL information to be accessed through the IPMB interface even
if the system is down.

SMBus Address Map

The table below lists the location, function, and address of each SMBus device used on the
ZT 5504.
Device
ADM1026
Ethernet A
