BS83B24C/BS83C40C
Touch Flash MCU
• PDS0 Register – BS83C40C
Bit 7
Name PDS0�
R/W R/W
POR 0
Bit 7~6 PDS07~PDS06: PD3 pin-shared function selection
00/01/10: PD3
11: KEY26
Bit 5~4 PDS05~PDS04: PD2 pin-shared function selection
00/01/10: PD2
11: KEY25
Bit 3~2 PDS03~PDS02: PD1 pin-shared function selection
00/01/10: PD1
11: KEY24
Bit 1~0 PDS01~PDS00: PD0 pin-shared function selection
00/01/10: PD0
11: KEY23
• PDS1 Register – BS83C40C
Bit 7
Name PDS1�
R/W R/W
POR 0
Bit 7~6 PDS17~PDS16: PD7 pin-shared function selection
00/01/10: PD7
11: KEY30
Bit 5~4 PDS15~PDS14: PD6 pin-shared function selection
00/01/10: PD6
11: KEY29
Bit 3~2 PDS13~PDS12: PD5 pin-shared function selection
00/01/10: PD5
11:KEY28
Bit 1~0 PDS11~PDS10: PD4 pin-shared function selection
00/01/10: PD4
11: KEY27
• PES0 Register – BS83C40C
Bit 7
Name PES0�
R/W R/W
POR 0
Bit 7~6 PES07~PES06: PE3 pin-shared function selection
00/01: PE3
10: CTP
11: KEY34
Bit 5~4 PES05~PES04: PE2 pin-shared function selection
00/01/10: PE2/CTCK
11: KEY33
Bit 3~2 PES03~PES02: PE1 pin-shared function selection
00/01/10: PE1
11: KEY32
Rev. 1.00
6 5 4
PDS06 PDS05 PDS04
R/W R/W R/W
0 0 0
6 5 4
PDS16 PDS15 PDS14
R/W R/W R/W
0 0 0
6 5 4
PES06 PES05 PES04
R/W R/W R/W
0 0 0
�3
3 2 1
PDS03 PDS0� PDS01
R/W R/W R/W
0 0 0
3 2 1
PDS13 PDS1� PDS11
R/W R/W R/W
0 0 0
3 2 1
PES03 PES0� PES01
R/W R/W R/W
0 0 0
�e���a�� 0�� �01�
0
PDS00
R/W
0
0
PDS10
R/W
0
0
PES00
R/W
0
