SLEDC01~SLEDC00: PA3~PA0 Source Current Selection
Bit 1~0
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
• SLEDC1 Register – BS83B24C
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
SLEDC15~SLEDC14: PD1~PD0 Source Current Selection
Bit 5~4
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
SLEDC13~SLEDC12: PC7~PC4 Source Current Selection
Bit 3~2
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
SLEDC11~SLEDC10: PC3~PC0 Source Current Selection
Bit 1~0
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
• SLEDC1 Register – BS83C40C
Bit 7
Name SLEDC1� SLEDC16 SLEDC15 SLEDC14 SLEDC13 SLEDC1� SLEDC11 SLEDC10
R/W R/W
POR 0
SLEDC17~SLEDC16: PD7~PD4 Source Current Selection
Bit 7~6
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
SLEDC15~SLEDC14: PD3~PD0 Source Current Selection
Bit 5~4
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
Bit 3~2 SLEDC13~SLEDC12: PC7~PC4 Source Current Selection
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
Bit 1~0 SLEDC11~SLEDC10: PC3~PC0 Source Current Selection
00: Source current=Level 0 (min.)
01: Source current=Level 1
10: Source current=Level 2
11: Source current=Level 3 (max.)
