BS83B24C/BS83C40C
Touch Flash MCU
• INTC1 Register
Bit 7
Name DE�
R/W R/W
POR 0
Bit 7 DEF: Data EEPROM interrupt request flag
0: No request
1: Interrupt request
Bit 6 TB1F: Time Base 1 interrupt request flag
0: No request
1: Interrupt request
Bit 5 TB0F: Time Base 0 interrupt request flag
0: No request
1: Interrupt request
Bit 4 USIMF: USIM Module interrupt request flag
0: No request
1: Interrupt request
DEE: Data EEPROM interrupt control
Bit 3
0: Disable
1: Enable
TB1E: Time Base 1 interrupt control
Bit 2
0: Disable
1: Enable
TB0E: Time Base 0 interrupt control
Bit 1
0: Disable
1: Enable
Bit 0 USIME: USIM Module interrupt control
0: Disable
1: Enable
• INTC2 Register – BS83C40C
Bit 7
Name —
R/W —
POR —
Bit 7~5 Unimplemented, read as "0"
Bit 4 MF1F: Multi-function 1 interrupt request flag
0: No request
1: Interrupt request
Bit 3~1 Unimplemented, read as "0"
Bit 0 MF1E: Multi-function 1 interrupt control
0: Disable
1: Enable
• MFI0 Register
Bit 7
Name —
R/W —
POR —
Bit 7~6 Unimplemented, read as "0"
PTMAF: PTM Comparator A match interrupt request flag
Bit 5
0: No request
1: Interrupt request
Rev. 1.00
6 5 4
TB1� TB0� USIM�
R/W R/W R/W
0 0 0
6 5 4
— — M�1�
— — R/W
— — 0
6 5 4
— PTMA� PTMP�
— R/W R/W
— 0 0
153
3 2 1
DEE TB1E TB0E
R/W R/W R/W
0 0 0
3 2 1
— — —
— — —
— — —
3 2 1
— — PTMAE
— — R/W
— — 0
�e���a�� 0�� �01�
0
USIME
R/W
0
0
M�1E
R/W
0
0
PTMPE
R/W
0
