Technical Specifications

Dew Point
Measurement Accuracy
Repeatability
Sensitivity
Response
Dew-Point Sensor
Sensor
Dew Point Range (°C)
Temperature Range
(°C)
% RH Range @ 23°C
Material
Corrosion & Saturation
Protection
Mirror Temperature
Measurement
Recommended Sample
Flow
Pressure
Process connection
Temperature
Measurement Accuracy
Temperature
Measurement
Cable length
Sensor cable
Pressure Measurement
Accuracy
Pressure Measurement
Range
Process Connection
Michell Instruments
Performance
±0.15°C
±0.05°C
±0.01°C
Stable measurement at +10°C dp within 1 minute
Single Stage
-25 to +90
-40 to +90
2.25 to 100
POM (head)
Aluminium (body)
Active Component Isolation System
Pt1000, Class A
Ambient (environmental measurements)
to 2Nl/min (flowing sample)
2500 kPag max
M36x1.5-6g
Remote PRT
±0.1°C
Pt100, Class A
Cables
0.3, 3, 5, 10 & 20m lengths available (cables can be combined)
Standard: 90°C max temperature
High temperature: 120°C max temperature
Remote Pressure Sensor (Optional)
±0.25% FS
0-160KPa or 0-2500KPa
1/8" NPT-M
Optidew User's Manual
Dual Stage
-40 to +90
-40 to +90
0.45 to 100
POM (head)
Aluminium (body)
Harsh Environment
-40 to +120
-40 to +120
0.45 to 100
PEEK (head)
Aluminium (body)
47
