Optidew User's Manual

3.1.3. Customizable Readouts

The three readouts on the Main Screen can be configured by the User to show any of the
following parameters:
• Dew Point
• Temperature
• Pressure
• % Relative Humidity
• g/m3
• g/kg
• ppmV
• %Vol
• Twb
• wvp (water vapour pressure)
• Dew Point (pressure corrected)
To change a parameter:
1. Touch the readout once to enable parameter selection
2. Touch the left or right arrows to select the parameter to be displayed
3. Touch the centre of the readout to confirm selection

3.1.4. Locking the analyzer

From firmware version 1.0.1 onwards it is possible to lock the analyzer so unauthorised users
cannot change any settings. Go to the SETUP page and in the bottom left hand corner there is
a padlock icon on that is greyed out. Pressing it will bring up the passcode entry screen where
you will need to enter 5491. The padlock icon will become solid to show it is now activated.
After five minutes, this function will lock the analyzer (you will need to return to the main screen).
To unlock the screen, you must enter 5491.
It is possible to deactivate the function before it is triggered or after activation by simply pressing
the solid padlock item in the Settings Menu.
18 97551 Issue 4.1, October 2019
