Optidew User's Manual
24 0018
25 0019
30 001E
31 001F
Instrument Status
33 0021
34 0022
35 0023
36 0024
37 0025
38 0026
39 0027
52
float Water Vapour Pressure MS
R
Water Vapour Pressure LS
R
uint16 Temperature Unit
R
0 = °C
1 = °F
uint16 Pressure Unit
R
0=psig
1=psia
2=barg
3=bara
4=kPa
uint16 Operating Mode
R
5=MaxCool
6=DCC
7=Hold
8=Measure
9=Standby
10=FAST
13=System Failure
uint16 Mode Hrs Left
R
uint16 Mode Mins Left
R
uint16 Mode Secs Left
R
uint16 Sensor Status
R
1=Cooling
2=Heating
3=In-Control
4=Idle
uint16 Fault Status 1
R
bit0=Optics Search Fail
bit1=Optics Min Limit
bit2=Optics Max Limit
bit3=Ambient Pt100 Fail
bit4=Mirror Pt100 Fail
bit5=Mirror Overheat
bit6=Loop Fail (Pressure Tx)
bit7=Heating Saturation
bit8=Cooling Saturation
uint16 Fault Status 2
R
Units = Pascal
Set using register 100
Set using register 101
97551 Issue 4.1, October 2019
