Optidew User's Manual
Control Unit
Resolution
Measurement Units
Enclosure
Material
Analog Outputs
Digital Communications
Alarms
Inputs
Data Logging
Ingress Protection
Dimensions
Weight
Display
Environmental
Conditions
Supply Voltage
Power consumption
48
1 or 2 decimal places selectable
°Cdp or °Fdp
Relative humidity - %
Absolute humidity - g/m
Mixing Ratio - g/kg
Wet Bulb Temperature (Twb) - °C, °F
Water Vapour Pressure (wvp) - Pa
Ambient Temperature - °C, °F
pressure converted DP - °C, °F
pressure - KPa, Bara, Barg, Psia, Psig
Wall Mount
ABS
Two mA outputs, selectable 0-20,
4-20 (maximum load 500Ω)
Modbus RTU over RS485
Modbus TCP over Ethernet
(optional)
1x Process Relay,
1x Alarm Relay,
Both Form C, 1A, 30V DC
4-20mA for pressure sensor
SD card slot (optional)
IP54
IP65 (optional)
220x175x75mm
Control unit: 1.5kg
Sensor: 200g
Analyzer 5.7" color touch screen.
Transmitter Status LED
-20 to +50°C, up to 100%RH non-condensing or
100% RH condensing with IP65 version
100 to 240V AC, 50 to 60Hz
30VA max
3 , ppm %Vol
V,
ABS
Two mA outputs, selectable 0-20,
4-20 (maximum load 500Ω)
Modbus RTU over USB & RS485
Modbus TCP over Ethernet
(optional)
1x Process Relay,
1x Alarm Relay,
Both Form C, 1A, 30V DC
4-20mA for pressure sensor
SD card slot
IP54
220x175x118mm
Control unit: 1.5kg
Sensor: 200g
5.7" color touch screen
