2. INSTALLATION

2.1. Unpacking the instruments

It is recommended that all packaging is retained, in case products are returned for service or
calibration. Alternatively, if you choose to dispose of the packaging materials, ensure they are
recycled in accordance with local legislation.
Standard contents in the box:
• Calibration Certificate
• 6-Way Alarm Relay Connector
• 8-Way Analogue Output / RS485 Connector
• Pt100 Temperature Probe (with separate or integrated M12cable, depending on model)
• Chilled Mirror Monitor
• Chilled Mirror Sensor
• Chilled Mirror Sensor Cable
• Mains Cable

2.2. Mounting

Optidew 401
The Optidew 401 is designed to be placed on a bench or table during operation. Alternatively, it
can be used inside the optional Transport Case.
Optidew 501
The Optidew can be wall mounted using the four mounting points on each corner (see figure 2
for mounting point dimensions). It is possible to install the Optidew 501 outside, providing it is
shielded from direct sunlight and the climate is within the environmental requirements listed in
Appendix A Technical Specifications. It is highly recommended to choose the weatherproof option
if the installation will be outdoors.
Fixings
Secure using 4 off suitable screws or bolts plus washers (M4 x 15 to M6 x 15mm). Unit must be
secured to a solid surface (e.g. brick, concrete, wood min 10mm thick) or to a metal chassis plate
of minimum 3mm thickness.
Michell Instruments 5
