Technical Information
STANDARDS
SPEED
CONNECTOR
ANTENNA
GPS Interface
STANDARDS
CONNECTOR
ANTENNA
Configuration Interface
INTERFACES
PROTOCOLS
SPEED
CONNECTOR
Power
INPUT VOLTAGE
INPUT CURRENT
MAXIMUM POWER
Dimensions and Weight
TYPE
LENGTH x WIDTH x HEIGHT
WEIGHT
18
802.11n a/b/g 2x2
802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b: 1, 2, 5.5, 6, 9, and 11 Mbps
802.11g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54, and m0-m15
Up to 2 coaxial connectors, type N
The antennas are supplied independently to the device
SiRFstarIV
FME male
3.3 V Active. These are supplied independently to the device
This can be configured in two modes:
Asynchronous Port :
V24 DCE. Does not permit Hardware flow control.
Local Console:
V.24 DCE only 8-N-1, without flow control.
Asynchronous Port:
AT, PPP, GPS-DATA
Asynchronous Port:
300 at 115,200 bps
Local console:
9,600 bps (configurable up to 115,200)
DB9 female located on the front panel of the device.
+110 V DC
150 mA @110 V DC
15 W
Ruggedized casing for 19" rack
240 x 445 x 44 mm
3.8 kg
