Index

[`A; b L] Alarm Blocking 41, 64
[AC; L F] AC Line Frequency 42, 62
[AC; S P] Active Set Point 32
[Ad; M ] Address Modbus 43
[`Ad; s ] Address Standard Bus 43
[A; d SP] Alarm Display 41
[`A; h i] Alarm High Set Point 31, 63
[`A; h y] Alarm Hysteresis 41, 63
[``Ai] Analog Input Menu 29, 34
[`ain] Process Value 29
[`A; L A] Alarm Latching 41, 63
[AL; E 1] [AL; E 2] [AL; E 3] [AL; E 4]
Alarm Error 1 to 4 24, 27
[`A; L g] Alarm Logic 41
[AL; h 1] [AL; h 2] [AL; h 3] [AL; h 4]
Alarm High 1 to 4 24, 27
[AL; L 1] [AL; L 2] [AL; L 3] [AL; L 4]
Alarm Low 1 to 4 24, 27
[ALM] Alarm Menu 31, 40
[`A; L o] Alarm Low Set Point 31, 63
[`A; S d] Alarm Sides 41
[`A; S i] Alarm Silencing 41, 64
[A; t SP] Autotune Set Point 30, 54
[Attn] Attention 24, 26, 27, 63, 64
[`A; t y] Alarm Type 40, 63
[`AUt] Autotune 30, 54
[AUt1] Autotune, Home Page 26
[bAUd] Baud Rate 43
[`C; A g] Cool Algorithm 37, 60
[`CAL] Calibration Menu 52
[`C; C r] Cool Output Curve 37, 59
[`C; d t] Current Detect Threshold 41
[`C; E r] Current Error 24, 27, 31, 64
[`C_F] Display Units 42
[`C; h i] Current High Set Point 31,
64
[`C; h y] Cool Hysteresis 30, 60
[C; L Ed] Communications Indicator
Light 52
[`C; L o] Current Low Set Point 31, 64
[`C; M ] Control Mode 30, 60
[C; M 1] Control Mode, Home Page 26
[C; M A] Control Mode Active 29
[C; o FS] Current Offset 41
[CoM] Communications Menu 43
[`C; P b] Cool Proportional Band 30,
55, 61
[`C; P r] Cool Power 29, 55
[C; P r1] Cool Power, Home Page 26
[`C; S C] Scaling 41
[`C; S d] Current Sides 41
[`C; S i] Current Source Output
Instance 42
[`C; S P] Closed Loop Set Point 30
[`C; S P] Closed Loop Working Set
Point 29
[`CU; r ] Current Read 31
[`CU; r ] Current Reading Enable 41
®
Watlow E Z-ZONE PM Inte gr a t e d Con tr ol le r
[CUrr] Current Menu 31, 41
[CUSt] Custom Menu 26, 50, 54
[dAtE] Date of Manufacture 51
[``db] Dead Band 31, 62
[`dEC] Decimal 35
[diAg] Diagnostics Menu 51
[`dio] Digital Input/Output Menu
29
[`dir] Direction 35
[`do; S ] Digital Output State 29
[EiP; E ] Ethernet/IP™ Enable 44
[`Ei; S ] Event Input Status 29
[ELi; o ] Electrical Input Offset 52, 56
[ELi; S ] Electrical Input Slope 52, 56
[ELo; o ] Electrical Output Offset 52
[ELo; S ] Electrical Output Slope 52
[`End] End 48
[`End] End Type 47
[Ent1] Active Event Output 1 32
[Ent1] Event Output 1 47
[Ent2] Active Event Output 2 32
[Ent2] Event Output 2 47
[Er; i 1] [Er; i 2] Error Input 1 or 2
24, 27
[FAiL] Input Error Failure 38, 59
[`FiL] Filter 35
[``Fi] Digital Input Function In-
stance 36
[``Fi] Function Key Instance 42
[``Fi] Digital Output Function
Instance 35
[``Fi] Output Function Instance 39,
40
[``Fn] Digital Input Function 36, 42
[[``Fn] Digital Output Function 35
[``Fn] Output Function 39, 40, 55
[`FUn] Function Key Menu 42
[gLbL] Global Menu 42
[`gSd] Guaranteed Soak Deviation
43
[`gSE] Guaranteed Soak Enable 43
[`h; A g] Heat Algorithm 37, 60
[`h; E r] Heater Error 24, 27, 31, 64
[`h; h y] Heat Hysteresis 30, 60
[hoUr] Hours 47
[`h; P b] Heat Proportional Band 30,
55, 61
[`h; P r] Heat Power 29, 55
[h; P r1] Heat Power, Home Page 26
[`h; S P] Control Loop High Set Point
38
[`i; C A] Calibration Offset 29, 56–57
[`id; S ] Idle Set Point 30
[id; S 1] Idle Set Point, Home Page 26
[`i; E r] Input Error Latching 35
[`i; E r] Input Error Status 29
[`iid] Instance 50
[iP; A 1] IP Actual Address Part 1 51
72
• •
[iP; A 2] IP Actual Address Part 2 51
[iP; A 3] IP Actual Address Part 3 52
[iP; A 4] IP Actual Address Part 4 52
[iP; F 1] IP Fixed Address Part 1 43
[iP; F 2] IP Fixed Address Part 2 43
[iP; F 3] IP Fixed Address Part 3 44
[iP; F 4] IP Fixed Address Part 4 44
[iP; g 1] IP Fixed Gateway Part 1 44
[iP; g 2] IP Fixed Gateway Part 2 44
[iP; g 3] IP Fixed Gateway Part 3 44
[iP; g 4] IP Fixed Gateway Part 4 44
[iP; M ] IP Address Mode 43
[iP; S 1] IP Fixed Subnet Part 1 44
[iP; S 2] IP Fixed Subnet Part 2 44
[iP; S 3] IP Fixed Subnet Part 3 44
[iP; S 4] IP Fixed Subnet Part 4 44
[`is; a ] Alarm Source Instance 40
[``JC] Jump Count 47
[``JC] Jump Count Remaining 32
[``JL] Jump Loop 48
[``JS] Jump Step 47
[`leu] Digital Input Level 36, 42
[`L; d d] Open Loop Detect Deviation
38
[`L; d E] Open Loop Detect Enable 38
[`L; d t] Open Loop Detect Time 38
[`Lh; S ] Limit High Set Point 29
[`L; h y] Limit Hysteresis 36
[Li; E 1] [Li; E 2] Limit Error 1 or 2 24,
27
[Li; h 1] [Li; h 2] Limit High 1 or 2 24,
27
[Li; L 1] [Li; L 2] Limit Low 1 or 2 24,
27
[LiM] Limit Menu 29, 36
[`Lin] Linearization 34
[`L; i t] Limit Integrate 37
[`LL; S ] Limit Low Set Point 29
[`LoC] Lockout Menu 50
[LoC; o ] Lock Operations Page 50, 65
[LoC; P ] Lock Profi ling Page 50, 65
[Loop] Loop Menu 30, 37
[LP; o 1] Loop Open Error 24, 27
[LP; r 1] Loop Reversed Error 24, 27
[`L; S d] Limit Sides 36
[`L; S P] Loop Low Set Point 38
[MAn] Manual Power 38
[Mb; E ] Modbus TCP Enable 44
[M; h L] Modbus Word Order 43
[Min] Minutes 47
[Mon] Monitor Menu 29
[`Mu] Electrical Measurement 52,
56
[`o; C A] Calibration Offset 39
[`o; C t] Output Control 35, 40
[`o; h i] Output High Power Scale
35, 39, 40
[`o; L o] Output Low Power Scale
Ap p e nd i x
