Dis- Parameter Name
play Description
[otpt] [```1]
[`Set] [otpt]
Output Menu Output 1
[`o; t y] Output (1 or 3)
Type
[ o.ty]
Select whether the process output will op-
erate in volts or milliamps.
[``Fn] Output (1 or 3)
[ Fn] Function
Select what function will drive this output.
[`r; S r] Output (1 or 3)
[ r.Sr] Retransmit Source
Select the value that will be retransmitted.
[``Fi] Output (1 or 3)
[ Fi] Function Instance
Select which source instance will drive the
output.
[`S; L o] Output (1 or 3)
[ S.Lo] Scale Low
Set the minimum value of the process out-
put range in electrical units.
[`S; h i] Output (1 or 3)
Scale High
[ S.hi]
Set the maximum value of the process out-
put range in electrical units.
[`r; L o] Output (1 or 3)
[ r.Lo] Range Low
Set the minimum value of the retransmit
value range in process units. When the
retransmit source is at this value, the
retransmit output will be at its Scale Low
value.
[`r; h i]
Output (1 or 3)
[ r.hi] Range High
Set the maximum value of the retransmit
value range in process units. When the
retransmit source is at this value, the re-
transmit output will be at its Scale High
value.
[`o; L o] Output (1 or 3)
Low Power Scale
[ o.Lo]
Set the minimum value of the output
range.
[`o; h i] Output (1 or 3)
[ o.hi] High Power Scale
Set the maximum value of the output
range.
[`o; C A]
Output (1 or 3)
[ o.CA] Calibration Offset
Set an offset value for a process output.
Note: Some values will be rounded off to fit in the four-character display. Full values can be read with other interfaces.
